| . . | YT30V00001F4 | [1] | VALVE | KOBASSY, CONTROL |
| 1. | NSS | [1] | NOT SERVICED SEPARATELY | CONBODY |
| 2. | YN01V00004S006 | [1] | O-RING | KOB |
| 3. | ZD12P02200 | [4] | O-RING | KOB |
| 4. | ZD12P01600 | [3] | O-RING | KOB |
| 5. | YT30V00001S005 | [1] | COVER | KOB |
| 6. | ZS23C12030 | [4] | SCREW,Hex Socket Head, M12 x 30mm | KOBCAP |
| 16. | YT30V00001S016 | [2] | COVER | KOB |
| 17. | YT30V00001S017 | [1] | COVER | KOB |
| 18. | YT30V00001S018 | [8] | COVER | KOB |
| 19. | PH30V00009S011 | [7] | COVER | KOB |
| 20. | YT30V00001S020 | [15] | PLUG | KOB |
| 21. | YT30V00001S021 | [10] | CHECK VALVE | KOB |
| 22. | YT30V00001S022 | [10] | SPRING | KOB |
| 23. | YT30V00001S023 | [10] | SEAT | KOBSPRING |
| 24. | YT30V00001S024 | [8] | SEAT | KOBSPRING |
| 25. | PH30V00009S005 | [8] | CAPSCREW | KOBSCREW SPACER |
| 26. | YT30V00001S026 | [10] | SPRING | KOB |
| 27. | YT30V00001S027 | [2] | SPOOL | KOBBOLT, SPACER Superseded by part number: YT30V00001R220 |
| 33. | YT30V00001S033 | [2] | GUIDE | KOBPISTON |
| 34. | YT30V00001S034 | [2] | PISTON | KOB |
| 35. | YT30V00001S035 | [2] | SPRING | KOB |
| 36. | YT30V00001S036 | [2] | PISTON | KOB |
| 37. | YT30V00001S037 | [1] | PLUG | KOB |
| 38. | YT30V00001S038 | [1] | VALVE | KOBSHUTTLE |
| 39. | YT30V00001S039 | [1] | BOLT | KOBSPACER |
| 40. | YR30V00001S111 | [1] | VALVE | KOBCHECK |
| 41. | YW01V00002S027 | [7] | PLUG | KOB |
| 42. | 2436U1317S87 | [1] | SPRING | KOB |
| 43. | YT30V00001S043 | [1] | PLUG | KOB |
| 44. | ZD12P01090 | [1] | O-RING | KOB |
| 45. | 2436U1317S22 | [2] | PLUG | KOB |
| 46. | 2483U234S6 | [1] | BALL | KOB |
| 50. | PL30V00007S034 | [1] | PLUG | KOB |
| 51. | ZR26X01100 | [2] | RING | KOBRETAINING |
| 52. | PH30V00009S007 | [18] | O-RING | KOB |
| 53. | ZD12P00600 | [2] | O-RING | KOB |
| 54. | ZD12P00800 | [1] | O-RING,1.9mm Thk x 7.8mm ID, 90 Duro | KOB |
| 55. | ZD12P01000 | [1] | O-RING | KOB |
| 56. | ZD12P01100 | [2] | O-RING | KOB |
| 57. | ZD12P01400 | [11] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 58. | ZD12P01500 | [16] | O-RING | KOB |
| 59. | ZD12P01800 | [3] | O-RING | KOB |
| 60. | YT22V00003F1 | [1] | VALVE | KOBASSY, MAIN RELIEF, SEE FIG. 07-007 |
| 61. | YT22V00004F1 | [6] | VALVE | KOBASSY, OVERLOAD RELIEF, SEE FIG. 07-008 |
| 62. | YR30V00001S116 | [1] | PLUG | KOB |
| 63. | ZD12P02400 | [1] | O-RING | KOB |
| 64. | 2436U1427S25 | [3] | PLUG | KOB |
| 65. | YT30V00001S065 | [1] | PIN | KOBSTOPPER |
| 66. | YT30V00001S066 | [1] | COVER | KOB |
| 67. | YT30V00001S067 | [1] | PISTON | KOB |
| 68. | YT30V00001S068 | [1] | BODY | KOBPILOT |
| 69. | YT30V00001S069 | [1] | PIN | KOBGUIDE |
| 70. | YT30V00001S070 | [1] | SPRING | KOB |
| 71. | YT30V00001S071 | [1] | O-RING | KOB |
| 72. | YT30V00001S072 | [1] | O-RING | KOB |
| 73. | YN01V00003S027 | [2] | PLUG | KOB |
| 74. | ZS23C06055 | [2] | CAPSCREW,Hex Socket Head, M6 x 55mm | KOBSCREW CAP |
| 75. | ZD85P01090 | [2] | RING | KOBBACK UP |
| 79. | YT30V00001S079 | [1] | VALVE | KOBCHECK |
| 81. | PH30V00009S019 | [32] | CAPSCREW | KOBSCREW CAP |
| 82. | YT30V00018S018 | [6] | CAPSCREW | KOBSCREW CAP |
| . . | YT30V00001R100 | [1] | SPOOL | KOBSTRAIGHT TRAVEL KIT (SPOOL + SPRING) CONSISTS OF REF. 7 (1), 23 (1), 24 (1), 25 (1), 26 (1) |
| . . | YT30V00001R110 | [1] | SPOOL | KOBTRAVEL KIT (SPOOL + SPRING) CONSISTS OF REF. 8 (1), 23 (1), 24 (1), 25 (1), 26 (1) |
| . . | YT30V00001R130 | [1] | SPOOL | KOBBOOM KIT (SPOOL + SPRING) CONSISTS OF REF. 10 (1), 23 (1), 24 (1), 25 (1), 26 (1) |
| . . | YT30V00001R140 | [1] | SPOOL | KOBARM KIT (SPOOL + SPRING) CONSISTS OF REF. 11 (1), 23 (1), 24 (1), 25 (1), 26 (1) Superseded by part number: YT30V00001R230 |
| . . | YT30V00001R150 | [1] | SPOOL | KOBBUCKET KIT (SPOOL + SPRING) CONSISTS OF REF. 12 (1), 23 (1), 24 (1),25 (1), 26 (1) |
| . . | YT30V00001R160 | [1] | SPOOL | KOBBOOM CONFLUENCE KIT (SPOOL + SPRING) CONSISTS OF REF. 13 (1), 23 (1), 26 (1), 27 (1) |
| . . | YT30V00001R170 | [1] | SPOOL | KOBCUT & ARM CONFLUENCE KIT (SPOOL + SPRING) CONSISTS OF REF. 15 (1), 23 (1), 24 (1), 25 (1), 26 (1), 39 (1), 40 (1), 42 (1), 54 (1) |
| . . | YT30V00001R190 | [1] | LOCK | KOBVALVE KIT CONSISTS OF REF. 16 (1), 33 (1), 45 (1), 56 (1) |
| . . | YT30V00001R200 | [1] | VALVE | KOBSHUTTLE KIT CONSISTS OF REF. 37 (1), 38 (1), 46 (1) |
| . . | YT30V00001R210 | [1] | SPOOL | KOBREPAIR KIT CONSISTS OF REF. 23 (1), 24 (1), 25 (1) 26 (1), 77 (1) |
| . . | YT30V00001R220 | [1] | SPOOL | KOBREPAIR KIT CONSISTS OF REF. 23 (1), 26 (1), 27 (1) 78 (1) |
| . . | YT30V00001R230 | [1] | SPOOL | KOBARM KIT (SPOOL + SPRING) CONSISTS OF REF. 23 (1), 24 (1), 25 (1) 26 (1), 80 (1) |
