纽荷兰零件查询(E70SR) - MIDI CRAWLER EXCAVATOR ASN YT04-07175 (07-003[01]) - VALVE ASSY, CONTROL (OPTION), P/N YT30V00017F1 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
409 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT30V00017F1 | [1] | VALVE | KOBASSY, CONTROL Superseded by part number: YT30V00007F1 |
| 1. | NSS | [1] | NOT SERVICED SEPARATELY | CONBODY |
| 8. | YT30V00001S020 | [2] | PLUG | KOB |
| 9. | YT30V00001S021 | [2] | CHECK VALVE | KOB |
| 10. | YT30V00001S022 | [2] | SPRING | KOB |
| 11. | YR30V00001S115 | [1] | PLUG | KOB |
| 12. | YT30V00001S018 | [2] | COVER | KOB |
| 13. | PH30V00009S011 | [2] | COVER | KOB |
| 14. | PH30V00009S019 | [8] | CAPSCREW | KOBSCREW CAP |
| 15. | PH30V00009S007 | [4] | O-RING | KOB |
| 16. | ZD12P01500 | [2] | O-RING | KOB |
| 17. | ZD12P01800 | [1] | O-RING | KOB |
| 18. | 2436U1317S13 | [2] | PLUG | KOB |
| 19. | ZD12P01100 | [2] | O-RING | KOB |
| 20. | YT22V00004F1 | [2] | VALVE | KOBASSY, OVERLORD RELIEF, SEE FIG. 07-008 |
| . . | YT30V00010R100 | [1] | SWITCH | KOBREPAIR KIT CONSISTS OF REF. 2 (1), 4 (1), 5 (1), 6 (1), 7 (1) |
| . . | YT30V00010R110 | [1] | REPAIR KIT | KOBCONSISTS OF REF. 3 (1), 4 (1), 5 (1), 6 (1), 7 (1) |
