现代零件查询R500LC-7 ARM(3.38M, HEAVY DUTY, #0155-)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
834 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
63NB-20900
|
[1] |
ARM ASSY
|
|
| . |
63NB-20901
|
[1] |
ARM ASSY
|
|
| . |
63NB-20902
|
[1] |
ARM ASSY
|
|
| 1. |
63NB-29010
|
[1] |
ARM WA
|
|
| 1. |
63NB-29011
|
[1] |
ARM WA
|
|
| 1. |
63NB-29012
|
[1] |
ARM WA
|
|
| 1. |
63NB-29013
|
[1] |
ARM WA
|
|
| 2. |
61EN-13350
|
[2] |
BUSHING
|
|
| 3. |
61EN-12260
|
[2] |
BUSHING-BRONZE
|
|
| 4. |
S700-100208
|
[2] |
DUST SEAL-DKIY TYPE
|
|
| 5. |
S700-120209
|
[4] |
DUST SEAL-DKIY TYPE
|
|
| 5. |
S700-120209
|
[2] |
DUST SEAL-DKIY TYPE
|
|
| 6. |
S651-810002
|
[2] |
NIPPLE-GREASE
|
|
| 7. |
61EN-17150
|
[2] |
BUSHING
|
|
| 7. |
61KH-89200
|
[2] |
BUSHING
|
|
| 8. |
63NB-27410
|
[2] |
PLATE-COVER
|
|
| 8. |
63NB-27411
|
[2] |
PLATE-COVER
|
|
| 9. |
S109-120256
|
[12] |
BOLT-SOCKET
|
|
| 10. |
S700-120309
|
[2] |
DUST SEAL-DKIY TYPE
|
|
