纽荷兰零件查询(E70SR) - MIDI CRAWLER EXCAVATOR ASN YT04-07175 (07-005[02]) - VALVE ASSY, CONTROL (OPTION), (P/N YT30V00019F1) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
217 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT30V00019F1 | [1] | VALVE | KOBASSY, CONTROL Superseded by part number: YT30V00019F3 |
| . . | YT30V00019F2 | [1] | VALVE | KOBASSY, CONTROL Superseded by part number: YT30V00019F4 |
| 1. | NSS | [1] | NOT SERVICED SEPARATELY | CONBODY |
| 2. | YT30V00001S020 | [5] | PLUG | KOB |
| 3. | ZD12P01500 | [5] | O-RING | KOB |
| 4. | ZD12P01400 | [2] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 5. | YT30V00001S021 | [1] | CHECK VALVE | KOB |
| 6. | YT30V00001S022 | [1] | SPRING | KOB |
| 9. | PH30V00009S007 | [2] | O-RING | KOB |
| 11. | PH30V00009S011 | [1] | COVER | KOB |
| 12. | PH30V00009S019 | [2] | CAPSCREW | KOBSCREW CAP |
| 14. | ZD12P02200 | [4] | O-RING | KOB |
| 15. | YN01V00004S006 | [1] | O-RING | KOB |
| 18. | YT30V00018S018 | [3] | CAPSCREW | KOBSCREW CAP |
| 23. | YT30V00001S035 | [1] | SPRING | KOB |
| 25. | YT30V00001S034 | [1] | PISTON | KOB |
| 26. | YT30V00001S036 | [1] | PISTON | KOB |
| 29. | PL30V00007S034 | [2] | PLUG | KOB |
| 31. | ZD12P01800 | [3] | O-RING | KOB |
| 32. | ZD12P00600 | [1] | O-RING | KOB |
| 34. | YR30V00001S115 | [2] | PLUG | KOB |
| 35. | YT22V00004F1 | [1] | VALVE | KOBASSY, OVERLORD RELIEF, SEE FIG. 07-008 |
| 37. | ZD12P01600 | [1] | O-RING | KOB |
| . . | YR30V00011R130 | [1] | REPAIR KIT | KOBCONSISTS OF REF. 7 (1), 8 (1), 10 (1), 13 (1), 16 (1), (F1 ONLY) |
| . . | LF30V00001R100 | [1] | SPOOL | KOBREPAIR KIT CONSISTS OF REF. 7 (1), 8 (1), 10 (1), 16 (1), 40 (1), (F2 ONLY) |
