| . . | YT15V00008F1 | [1] | MOTOR | KOBASSY (PROPELLING) |
| 1. | LF15V00002S001 | [1] | HUB | KOB |
| 2. | NSS | [1] | NOT SERVICED SEPARATELY | CONSPINDLE |
| 6. | LF15V00002S006 | [1] | GEAR | KOB |
| 8. | LF15V00002S008 | [1] | COVER | KOB |
| 15. | LF15V00002S015 | [1] | SHAFT | KOB |
| 17. | LF15V00002S017 | [28] | PIN | KOB |
| 18. | 2441U815S18 | [1] | RING | KOB |
| 19. | LF15V00002S019 | [3] | BOLT | KOBREAMER |
| 20. | 2441U532S19 | [3] | RING | KOB |
| 21. | LF15V00002S021 | [2] | BEARING | KOBBALL |
| 24. | ZR16X01900 | [1] | SNAP RING | KOBRETAINING |
| 25. | ZR16X02500 | [6] | RING | KOBRETAINING |
| 28. | ZD12P00800 | [4] | O-RING,1.9mm Thk x 7.8mm ID, 90 Duro | KOB |
| 29. | ZD11G23000 | [1] | O-RING,229.30mm ID x 240.70mm OD x 5.70mm | KOB |
| 30. | LF15V00002S030 | [1] | O-RING | KOB |
| 33. | YT15V00008S033 | [1] | PLUG | KOB |
| 34. | YR15V00002S121 | [4] | PLUG | KOB |
| 35. | ZD12P01400 | [7] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 36. | 2441U815S26 | [1] | BALL | KOB |
| 43. | LF15V00002S043 | [2] | PIN | KOB |
| 102. | LF15V00002S102 | [1] | SHAFT | KOB |
| 103. | YT15V00008S103 | [1] | PLATE | KOB |
| 104. | LF15V00002S104 | [1] | CYLINDER | KOBBLOCK |
| 107. | LF15V00002S107 | [1] | RETAINER | KOBPLATE |
| 108. | LF15V00002S108 | [1] | BALL | KOBTHRUST |
| 109. | LF15V00002S109 | [1] | PLATE | KOB |
| 110. | LF15V00002S110 | [2] | WASHER | KOB |
| 112. | LF15V00002S112 | [1] | PISTON | KOB |
| 113. | LF15V00002S113 | [8] | SPRING | KOB |
| 114. | LF15V00002S114 | [1] | SPRING | KOB |
| 115. | LF15V00002S115 | [2] | PLATE | KOB |
| 116. | LF15V00002S116 | [2] | PLATE | KOB |
| 132. | 2441U815S132 | [1] | SEAL | KOBOIL |
| 135. | LF15V00002S135 | [1] | O-RING | KOB |
| 141. | LF15V00002S141 | [1] | O-RING | KOB |
| 146. | LF15V00002S146 | [1] | RING | KOBSNAP |
| 149. | 2441U532S129 | [1] | BEARING | KOBBALL |
| 150. | LF15V00002S150 | [1] | BEARING | KOBBALL |
| 151. | LF15V00002S151 | [3] | ROLLER | KOB |
| 176. | LF15V00002S176 | [2] | SHAFT | KOB |
| 177. | YW15V00005S171 | [2] | PIN | KOB |
| 185. | YT15V00002S185 | [1] | SPRING | KOB |
| 224. | 2441U532S123 | [2] | PLUG | KOB |
| 225. | YR15V00002S125 | [2] | SEAT | KOBSPRING |
| 227. | LF15V00002S227 | [2] | CHECK VALVE | KOB |
| 228. | 2441U532S128 | [2] | SPRING | KOB |
| 230. | LF15V00002S230 | [2] | SPRING | KOB |
| 236. | ZD12P02600 | [2] | O-RING | KOB |
| 238. | ZD12P01800 | [6] | O-RING | KOB |
| 242. | 2441U815S141 | [2] | PIN | KOB |
| 245. | ZS23C12030 | [6] | SCREW,Hex Socket Head, M12 x 30mm | KOBCAP |
| 252. | YX15V00003S146 | [1] | PLUG | KOB |
| 268. | PH15V00009S268 | [1] | BALL | KOB |
| 275. | PY15V00006S154 | [10] | PLUG | KOB |
| 281. | LF15V00002S281 | [1] | SPRING | KOB |
| 282. | 2441U995S121 | [4] | PLUG | KOB |
| 284. | YT15V00008S284 | [2] | PLUG | KOB |
| 287. | LF15V00002S287 | [2] | CHECK VALVE | KOB |
| 288. | LF15V00002S288 | [2] | SLEEVE | KOB |
| 289. | LF15V00002S289 | [2] | PLUG | KOB |
| 290. | LF15V00002S290 | [2] | SPRING | KOB |
| 291. | ZD12P01200 | [2] | O-RING | KOB |
| 293. | LP22V00004S221 | [2] | SEAL | KOBPISTON |
| 294. | ZD85P01200 | [4] | BACK-UP RING | KOB |
| 295. | ZD85P01400 | [4] | RING | KOBBACK-UP |
| 296. | 2441U829S168 | [2] | BALL | KOB |
| 297. | LF15V00002S297 | [2] | ORIFICE | KOB |
| . . | LF15V00002R400 | [1] | REPAIR KIT | KOBCONSISTS OF REF. 2 (1), 3 (1), 19 (3) |
| . . | LF15V00002R410 | [1] | GEAR | KOBREPAIR KIT CONSISTS OF REF. 4 (1), 5 (1), 9 (3), 12 (6), 22 (6), 23 (6) |
| . . | LF15V00002R420 | [1] | GEAR | KOBREPAIR KIT CONSISTS OF REF. 7 (3) |
| . . | LF15V00002R430 | [1] | REPAIR KIT | KOBCONSISTS OF REF. 31 (2) |
| . . | LF15V00002R440 | [1] | REPAIR KIT | KOBCONSISTS OF REF. 105 (9), 106 (9) |
| . . | LF15V00002R450 | [1] | REPAIR KIT | KOBCONSISTS OF REF. 161 (1), 162 (1) |
| . . | YT15V00008R460 | [1] | REPAIR KIT | KOBCONSISTS OF REF. 28(2), 35(4), 201(1), 221(2), 223(1), 224(2), 225(2), 227(7), 228(2), 230(2), 236(2), 238(6), 252(1), 268(1), 271(1), 272(1), 275(10), 279(1), 280(4), 281(1), 282(4), 283(1), 284(2), 286(2), 287(2), 288 (2), 289 (2), 290 (2), 291 (2), 293 |
| . . | YT15V00008R470 | [1] | REPAIR KIT | KOBCONSISTS OF REF. 201 (1), 223 (1), 252 (1), 268 (1), 275 (10), 279 (1), 280 (4), 283 (1), 286 (2), 299 (1) |
| . . | LF15V00002R480 | [1] | SPOOL | KOBREPAIR KIT CONSISTS OF REF. 271 (1), 272 (1) |
| . . | LF15V00002R490 | [1] | SEAL KIT | KOBCONSISTS OF REF. 28 (4), 29 (1), 30 (1), 31 (2), 35 (7), 132 (1), 135 (1), 141 (1), 236 (2), 23 (6), 291 (2), 293 (2), 294 (4), 295 (4) |
| . . | YT15V00008R500 | [1] | REPAIR KIT | KOBCONSISTS OF REF. 2 (1), 3 (1) |
