纽荷兰零件查询(E70SR) - MIDI CRAWLER EXCAVATOR ASN YT04-07175 (07-056) - JOINT ASSY, SWIVEL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
928 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J12125F1 | [1] | FLEXIBLE LINK | KOBJOINT ASSY, SWIVEL Superseded by part number: 24100J12125F2 |
| . . | 24100J12125F2 | [1] | UNIVERSAL JOINT | KOBASSY, SWIVEL |
| 1. | 2422J3203 | [1] | BODY | |
| 2. | 2436J204 | [1] | STEM | KOB |
| 3. | 2436P256 | [1] | PLATE | KOBTHRUST |
| 4. | 2436P266 | [1] | COVER | KOB |
| 5. | 2445Z736 | [7] | GASKET | KOBASSY |
| 6. | 2445R152D1 | [2] | O-RING,5.7mm Thk x 79.6mm ID, 70 Duro | KOB(F1 ONLY) |
| 7. | ZD11G09500 | [1] | O-RING,94.40mm ID x 100.60mm OD x 3.10mm | KOB |
| 8. | ZS23C08020 | [2] | SCREW,Hex Socket Head, M8 x 20mm | KOBCAP |
| 9. | ZS23C08030 | [3] | SCREW,Hex Socket Head, M8 x 30mm | KOBCAP Superseded by part number: ZS28C08030 |
| 11. | 2420Z1036D3 | [2] | CLEVIS | KOB |
| 12. | ZE82T02000 | [1] | PLUG | KOB |
| 13. | ZE82T06000 | [2] | PLUG | KOB |
| 14. | YN22T00194P1 | [1] | TYPE PLATE | KOBNAME |
| 15. | YN55V01049P1 | [2] | SEAL,80.15mm ID x 91mm OD x 6mm Thk | KOB(F2 ONLY) |
