| 1. |
84807458
|
[1] |
GUARD
|
ZED
|
| 2. |
80120104
|
[1] |
SCREW
|
ZED
M8 x 20 Superseded by part number: 120104
|
| 3. |
89706690
|
[1] |
NUT,M8, Cl 8
|
ZED
Superseded by part number: 43362
|
| 4. |
80322358
|
[1] |
LOCK WASHER
|
ZED
8 MM Superseded by part number: 322358
|
| 5. |
84100274
|
[2] |
HINGE
|
ZED
|
| 6. |
120106
|
[1] |
BOLT,M8 x 1.25 x 45.45mm, Cl 8.8
|
NH
, Start Serial: D536 Superseded by part number: 16044024
|
| 7. |
80336455
|
[1] |
PLUG
|
ZED
Superseded by part number: 336455
|
| 8. |
84607865
|
[1] |
TUBE,800, 738 mm L
|
ZED
|
| 9. |
84015292
|
[1] |
LATCH
|
ZED
|
| 10. |
84100154
|
[1] |
LOCKING TAB
|
ZED
|
| 11. |
84607879
|
[1] |
DOOR
|
ZED
, Serial Range: -C535 Superseded by part number: 87393911, 87396160
|
| 11. |
87396160
|
[1] |
DOOR
|
ZED
, Start Serial: D536
|
| 12. |
84078857
|
[1] |
GAS STRUT
|
ZED
, Serial Range: -C535
|
| 12. |
87393911
|
[1] |
GAS STRUT
|
ZED
, Start Serial: D536
|
| 13. |
84807453
|
[1] |
SUPPORT
|
ZED
, Serial Range: -C535
|
| 13. |
87350802
|
[1] |
PROFILE
|
ZED
, Start Serial: D536
|
| 14. |
89837397
|
[2] |
GAS STRUT
|
ZED
, Serial Range: -C535 Superseded by part number: 9837397
|
| 15. |
84100271
|
[2] |
HINGE
|
ZED
|
| 16. |
89839580
|
[2] |
SCREW,Hex Soc Hd, M8 x 70, 8.8
|
ZED
|
| 17. |
80043442
|
[2] |
NUT,M8 x 1.25, Cl 8
|
ZED
Superseded by part number: 82034883
|
| 18. |
89837364
|
[4] |
BALL JOINT
|
ZED
, Serial Range: -C535 Superseded by part number: 9837417
|
| 19. |
86508568
|
[1] |
BOLT,Hex, M6 x 1 x 16mm, Cl 8.8
|
NH
|
| 20. |
80322357
|
[1] |
LOCK WASHER,Belleville, M6
|
ZED
Superseded by part number: 322357
|
| 21. |
15896221
|
[1] |
NUT,Hex, M6, 5.20mm High, Cl 10
|
ZED
Superseded by part number: 86500688
|
| 22. |
80338949
|
[1] |
CARRIAGE BOLT
|
ZED
M10 x 25 Superseded by part number: 338949
|
| 23. |
140045
|
[4] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 24. |
100016
|
[4] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 25. |
86507486
|
[1] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
