凯斯零件查询(LBX332P) - BIG RECTANGULAR BALER ''PACKER CUTTER'' (3/03-12/08) (09.01[01]) - GREASING Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
292 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84807249
|
[1] |
LUBE PUMP
|
ZED
(2, 30), 4 liter
|
| 2. |
84807379
|
[1] |
SMALL PUMP
|
ZED
K6
|
| 3. |
84437931
|
[1] |
WIRE HARNESS
|
ZED
|
| 4. |
84807284
|
[1] |
MANIFOLD
|
ZED
|
| 5. |
84807243
|
[1] |
HYD CONNECTOR
|
ZED
1/8" - 4 MM
|
| 5. |
84807375
|
[1] |
NIPPLE
|
ZED
1/8" - 6 MM
|
| 5. |
84807246
|
[1] |
HYD CONNECTOR
|
ZED
M6 - 6 MM
|
| 6. |
84807240
|
[1] |
NIPPLE
|
ZED
1/8" - 6 mm
|
| 7. |
84807244
|
[1] |
HYD CONNECTOR
|
ZED
1/8" - 4 MM
|
| 7. |
84807241
|
[1] |
NIPPLE
|
ZED
1/8" - 6 MM
|
| 8. |
84807376
|
[1] |
NIPPLE
|
ZED
1/8" - 6MM
|
| 9. |
84078760
|
[1] |
SENSOR
|
ZED
|
| 10. |
84807247
|
[1] |
COUPLING
|
ZED
M6 - 6 MM
|
| 10. |
84807242
|
[1] |
NIPPLE
|
ZED
1/8" - 6 MM Superseded by part number: 84807377
|
| 10. |
84807245
|
[1] |
COUPLING
|
ZED
1/8" - 4 MM
|
| 11. |
84807377
|
[1] |
COUPLING
|
ZED
1/8" - 6MM
|
| 12. |
84807297
|
[1] |
COUPLING
|
ZED
4 MM
|
| 12. |
84807298
|
[1] |
COUPLING
|
ZED
6 MM
|
| 12. |
84807299
|
[1] |
UNION
|
ZED
8 MM
|
| 13. |
84807289
|
[1] |
HOSE
|
ZED
8 MM, L= 10 M
|
| 13. |
84807290
|
[1] |
HOSE,6mm ID x 5000mm L
|
ZED
6 MM, L= 5 M
|
| 13. |
84807291
|
[1] |
HOSE
|
ZED
4 MM, L= 5 M
|
| 14. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
PLUG
|
| 15. |
84807418
|
[1] |
CHECK VALVE
|
ZED
4 MM
|
| 15. |
84807301
|
[1] |
END FITTING
|
ZED
6 MM
|
| 15. |
84807292
|
[1] |
HYD CONNECTOR
|
ZED
6 MM Superseded by part number: 2928867
|
| 16. |
84807296
|
[1] |
PLUG
|
ZED
1/8"
|
| 17. |
84807300
|
[1] |
WIRE CONNECTOR
|
ZED
|
| 18. |
84807283
|
[1] |
MANIFOLD
|
ZED
RH, 10/10
|
| 18. |
84807285
|
[1] |
MANIFOLD
|
ZED
RH, 14/14
|
| 19. |
84807282
|
[1] |
MANIFOLD
|
ZED
8/8
|
| 21. |
84807287
|
[1] |
MANIFOLD
|
ZED
LH, 22/22
|
| 22. |
84807286
|
[1] |
MANIFOLD
|
ZED
RH, 18/18
|
| 23. |
84807293
|
[1] |
SCREW ON COUPLING
|
ZED
|
| 24. |
84807288
|
[1] |
MANIFOLD
|
ZED
|
| 25. |
84807304
|
[1] |
LUBE NIPPLE
|
ZED
|
| 26. |
84807248
|
[1] |
HYD CONNECTOR
|
ZED
1/8" - 1/8"
|
| 28. |
84807295
|
[1] |
HYD CONNECTOR
|
ZED
|
| 29. |
84807391
|
[1] |
SUPPORT
|
ZED
Superseded by part number: 87495474
|
| 30. |
84807305
|
[1] |
VALVE PRESSURE RELIE
|
ZED
350 bar
|
| 31. |
84101701
|
[1] |
QUICK FILL PUMP
|
ATT
|
| 32. |
NS
|
[1] |
NOT SERVICED
|
BAS
|
| 33. |
84818125
|
[1] |
ELBOW UNION
|
ZED
|
