| 1. |
84078549
|
[1] |
SUPPORT
|
ZED
|
| 2. |
84320678
|
[2] |
BUSHING,33mm ID x 48mm OD x 42mm L
|
ZED
ASAE, O.D. 41,6 MM, I.D. 33 MM
|
| 2. |
84320900
|
[2] |
BUSHING,33mm ID x 48mm OD x 42mm L
|
ZED
ISO, O.D. 40,6MM, I.D. 33 MM
|
| 3. |
84053179
|
[1] |
DRAWBAR
|
ZED
(13)
|
| 3. |
84800505
|
[1] |
HITCH
|
ZED
|
| 4. |
84447434
|
[1] |
SUPPORT
|
ZED
|
| 5. |
84447435
|
[1] |
BEARING HOUSING
|
ZED
, Serial Range: -C479
|
| 5. |
84801178
|
[1] |
BEARING HOUSING
|
ZED
, Start Serial: D480 Superseded by part number: 84801177
|
| 6. |
445395
|
[1] |
RIVET,Pop, 4.8mm OD x 18.1mm L
|
IH
|
| 7. |
84041202
|
[1] |
SUPPORT
|
ZED
|
| 8. |
80430356
|
[8] |
CLAMP
|
ZED
Superseded by part number: 430356
|
| 9. |
84814948
|
[4] |
SUPPORT
|
ZED
|
| 10. |
89839053
|
[1] |
PIN
|
ZED
Superseded by part number: 9839053
|
| 11. |
89839054
|
[1] |
NUT
|
ZED
Superseded by part number: 9839054
|
| 12. |
84053718
|
[1] |
SHIELD
|
ZED
|
| 13. |
89838723
|
[1] |
HOOK
|
ZED
Superseded by part number: 87315871
|
| 14. |
84817201
|
[1] |
BALL BEARING,45mm ID x 85mm OD x 22mm W
|
ZED
|
| 15. |
84022857
|
[1] |
WASHER,17mm ID x 40mm OD x 9.2mm Thk
|
ZED
17 MM
|
| 16. |
89706702
|
[2] |
SCREW
|
ZED
M12 x 50 Superseded by part number: 9706702
|
| 17. |
80140048
|
[14] |
WASHER
|
ZED
16.4 MM Superseded by part number: 140048
|
| 18. |
84056523
|
[17] |
BOLT,Hex, M16 x 45mm, Cl 10.9
|
ZED
|
| 19. |
80392530
|
[14] |
NUT
|
ZED
Superseded by part number: 392530
|
| 20. |
80120044
|
[4] |
BOLT
|
ZED
M12 x 30 Superseded by part number: 120044
|
| 21. |
80130007
|
[1] |
COTTER PIN
|
ZED
Superseded by part number: 83903970
|
| 22. |
15896221
|
[4] |
NUT,Hex, M6, 5.20mm High, Cl 10
|
ZED
Superseded by part number: 86500688
|
| 23. |
80322357
|
[4] |
LOCK WASHER,Belleville, M6
|
ZED
6 MM Superseded by part number: 322357
|
| 24. |
80120056
|
[4] |
SCREW
|
ZED
M6 x 50 Superseded by part number: 120056
|
| 25. |
89706687
|
[2] |
SCREW
|
ZED
M12 x 30 Superseded by part number: 9706687
|
| 26. |
80140046
|
[6] |
WASHER
|
ZED
12.4 MM Superseded by part number: 140046
|
| 27. |
89706685
|
[6] |
NUT
|
ZED
M12 Superseded by part number: 9706685
|
| 28. |
80100038
|
[4] |
NUT
|
ZED
M12 Superseded by part number: 100038
|
| 29. |
80394630
|
[4] |
WASHER
|
ZED
13 MM Superseded by part number: 86625256
|
| 30. |
84045753
|
[1] |
CABLE
|
ZED
L= 600 MM Superseded by part number: 84159558
|
| 30. |
84056519
|
[1] |
CABLE
|
ZED
L= 1800 MM Superseded by part number: 84159559
|
| 31. |
84045754
|
[1] |
CLAMP BRACKET
|
ZED
|
| 32. |
84442666
|
[1] |
DRIVE BUSHING
|
ZED
Superseded by part number: 84111658
|
| 33. |
84442663
|
[1] |
HINGE,52.3mm ID x 90mm OD x 33mm L
|
ZED
|
| 34. |
80412689
|
[1] |
PIN
|
ZED
Superseded by part number: 412689
|
| 35. |
84814929
|
[1] |
LUBE NIPPLE
|
ZED
, Serial Range: -C479 Superseded by part number: N13505
|
| 35. |
323713
|
[1] |
LUBE NIPPLE,M6 x 1mm
|
ZED
, Serial Range: -F480535
|
| 35. |
321201
|
[1] |
ANGLE BAR
|
MOD
, Start Serial: D536
|
| 36. |
89837598
|
[1] |
SCREW
|
ZED
M24 x 90 Superseded by part number: 87015585
|
| 37. |
84041908
|
[1] |
BUSHING
|
ZED
|
| 38. |
89837597
|
[1] |
NUT
|
ZED
M24 Superseded by part number: 9837597
|
| 39. |
84041795
|
[1] |
WASHER,26mm ID x 82mm OD x 10mm Thk
|
ZED
|
| 40. |
80851086
|
[1] |
CHAIN
|
ZED
Superseded by part number: 854993
|
| 40. |
1032162
|
[1] |
CHAIN
|
CAS
|
| 41. |
86002360
|
[1] |
PIN
|
ZED
D= 32 MM
|
| 42. |
84005018
|
[1] |
PLUG
|
ZED
|
| 43. |
84442667
|
[1] |
BUSHING
|
PA
41 MM Superseded by part number: 84111660
|
| 44. |
84442665
|
[1] |
BUSHING,42mm ID x 56mm OD x 24mm L
|
PA
42 MM
|
| 45. |
84111710
|
[1] |
DIA KIT, HARVESTER
|
ATT
(32, 33)
|
| 46. |
84110275
|
[1] |
DIA KIT, HARVESTER
|
ATT
(33, 44)
|
| 47. |
84110276
|
[1] |
DIA KIT, HARVESTER
|
ATT
(33, 43) Superseded by part number: 6042690070, 84442663, 84111660
|
