神钢零件查询(K935) - EXCAVATOR SUPPLEMENT ASN LU00154 (1/76-12/03) (02-006[01]) - INSTAL, CAB Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
310 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J3338F11 | [1] | INSTAL, CAB (NA) | |
| 3. | ZM11C10020 | [4] | SCREW | KOBM10x1.50x20mm (Incls. Lockwasher) Superseded by part number: ZM12C10020 |
| 4. | 2416T6761D4 | [1] | RUBBER | RUBBER |
| 5. | 2414R157 | [1] | INSULATION, HEAT | INSULATION, HEAT |
| 7. | 2414R143D2 | [1] | FOAM INSULATION | KOB |
| 8. | 2414R139 | [1] | FOAM INSULATION | KOB |
| 9. | 2414R137 | [1] | FOAM INSULATION | KOB |
| 11. | 2414R158 | [1] | INSULATION, HEAT | INSULATION, HEAT |
| 12. | ZS17C16090 | [4] | CAPSCREW | CAPSCREW |
| 13. | ZW16X16000 | [4] | WASHER | KOBID 16 x OD 30 x Th 3.2mm |
| 14. | ZW26X16000 | [4] | LOCK WASHER | KOBID 16 x OD 28 x Th 4.0mm |
| 15. | ZS17C12030 | [4] | SCREW | KOBM12x1.75x30mm Superseded by part number: ZS18C12030 |
| 16. | ZW16X12000 | [4] | WASHER | KOBID 12 x OD 24 x Th 2.3mm |
| 17. | ZW26X12000 | [4] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 20. | 24100U159F1 | [1] | SEAT | SEAT |
| 28. | 2414R232D1 | [1] | INSULATION, HEAT | INSULATION, HEAT |
| 29. | ZS31C04006 | [2] | SCREW,Phillips Drive, Pan HD, M4 x 6mm | KOBM04x0.7x06mm |
| 30. | 2418Z707 | [2] | | |
| 32. | 24100X1857F4 | [1] | CAB ASSY SEE FIG. 02-012 | CAB ASSY SEE FIG. 02-012 |
