纽荷兰零件查询(E70SR) - MIDI CRAWLER EXCAVATOR ASN YT04-07175 (05-001) - FUEL LINES New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
870 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT21P00002F3 | [1] | FUEL LINES | |
| 5. | 2444R2492D360 | [1] | HOSE | KOB |
| 7. | 2444R2492D025 | [1] | HOSE | KOB |
| 8. | HX11Y04040DX | [1] | HOSE,6mm ID x 400mm L | KOB Superseded by part number: 72280610 |
| 9. | 2418Z1333D8 | [1] | PROTECTIVE SLEEVE,19.5mm ID x 23.8mm OD x 1100mm Length | KOB |
| 10. | PY01P01008D2 | [1] | TUBE | KOB |
| 11. | PY01P01008D4 | [2] | RIGID TUBE | KOB |
| 12. | PY01P01043D3 | [16] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| 13. | ZC16X01800 | [14] | CLIP | KOB |
| 14. | YN21P01003P1 | [1] | GROMMET | KOB |
| 15. | ZS18C08025 | [2] | SCREW,Hex, M8 x 25mm | KOBCAP |
| 16. | ZW26X08000 | [2] | LOCK WASHER | KOBLock Superseded by part number: 83990583 |
| 19. | ZM61C06025 | [2] | BOLT | KOBSEMS |
| 20. | YT21P01001P1 | [2] | WASHER | KOB |
| 21. | 2444R2492D290 | [1] | HOSE | KOB |
| 22. | 2444R2492D085 | [1] | HOSE | KOB |
| 23. | HX11F05080DX | [1] | HOSE | KOB Superseded by part number: HX11F05090DX |
| 24. | HX11F05030DX | [1] | HOSE | KOB Superseded by part number: HX11F05040DX |
| 25. | YR21P01008P1 | [1] | HOSE | KOB |
| 26. | PY01P01008D6 | [1] | TUBE | KOB |
| 27. | ZW16X10000 | [1] | WASHER | KOB |
| 28. | YR21P01009P1 | [1] | ELEC CONNECTOR | KOB |
| 29. | PY01P01043D5 | [3] | CABLE TIE,301mm L | KOB |
| 30. | 2432R225D14 | [1] | CLIP | KOB Superseded by part number: ZC46X46014 |
| 31. | YR22P00001P1 | [1] | PUMP | KOBFUEL |
| 32. | YJ21P01008P2 | [1] | FILTER | KOBFUEL Superseded by part number: VY12905255630 |
| 33. | ZS18C10020 | [1] | SCREW,Hex, M10 x 20mm | KOBCap |
| 34. | PY01P01043D8 | [2] | CABLE TIE,102mm L | KOB |
| 37. | YT13E00025F1 | [1] | HARNESS | KOBASSY, UPP Superseded by part number: YT13E01069P1 |
| 37-1. | YT13E01069P1 | [1] | HARNESS | KOB |
| 1. | 897218-6470 | [1] | SEPARATOR ASSY, WATER, ISUZU "Engine Parts" | |
| 2. | 515411-2231 | [2] | CONNECTOR, ISUZU "Engine Parts" | |
| 3. | 909572-0140 | [4] | PACKING, ISUZU "Engine Parts" | |
| 4. | 909572-3251 | [1] | BOLT, ISUZU "Engine Parts" | |
| 17. | 515759-0270 | [1] | BOLT (WITH GAUZE FILTER), ISUZU "Engine Parts" | |
| 18. | YT21P01002F1 | [1] | ELEC CONNECTOR | KOBASSY, ISUZU "Engine Parts" |
| 18-1. | 515411-2250 | [1] | CONNECTOR, ISUZU "Engine Parts" | |
| 18-2. | 109675-0231 | [1] | BOLT, ISUZU "Engine Parts" | |
| 18-3. | 115759-0010 | [2] | PACKING, ISUZU "Engine Parts" | |
| 35. | 897213-6680 | [1] | JOINT, ISUZU "Engine Parts" | |
