纽荷兰零件查询(E70SR) - MIDI CRAWLER EXCAVATOR ASN YT04-07175 (05-003[01]) - CONTROL LINES, REMOTE (BOOM SAFETY) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
546 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT06H00020F4 | [1] | CONTROL LINES, MAIN | |
| A1. | ZH32X04000 | [11] | 90 ELBOW,Male, 30° Fl, PF 1/4" x PF 1/4", O-Ring | KOB |
| A2. | HH55Q04004G1 | [4] | TEE,1/4" ORB x 1/4" JIC x 1/4" JIC | KOB |
| A3. | ZH22X04000 | [12] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB |
| A4. | 2444T2524 | [4] | HYD CONNECTOR | KOB |
| A6. | HH25R06004G2 | [1] | CONNECTION | KOB |
| A7. | 2444R1120D100 | [1] | HOSE | KOB |
| A8. | 2444R1120D120 | [1] | HOSE | KOB |
| A9. | 2444R1120D070 | [1] | HOSE | KOB |
| A10. | 2444R1120D160 | [1] | HOSE | KOB |
| A11. | 2420R349D075 | [2] | HOSE | KOB Superseded by part number: 2444R3019D3 |
| A12. | 2420R349D105 | [1] | HOSE,1050.00 mm | KOB |
| A13. | 2420R349D090 | [2] | HOSE,6.35mm ID x 900mm L | KOB |
| A14. | 2444Z2525 | [3] | HYD CONNECTOR | KOB |
| A15. | HH25R04004G3 | [1] | CONNECTION | KOB |
| A17. | PY01P01043D6 | [2] | CABLE TIE,4.80mm W x 383mm L | KOB |
| A18. | ZH42X04000 | [2] | 45 ELBOW,Male, 30° Fl, PF 1/4" x PF 1/4", O-Ring | KOB45 |
| A19. | 2444Z2894 | [4] | 90 ELBOW | KOB |
| A20. | ZH32X06000 | [1] | 90 ELBOW,Male, 30° Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 |
| A21. | ZH32X04006 | [3] | 90 ELBOW,Male, 30° Fl, PF 1/4" x PF 3/8", O-Ring | KOB |
| A23. | YT21V00002P1 | [1] | CHECK VALVE | KOBASSY |
| A24. | 2444R402D16 | [1] | CONNECTION | KOB |
| A26. | 2444Z3541 | [1] | CONNECTION | KOB Superseded by part number: 2444Z3759 |
| A27. | HH25X04004G3 | [1] | CONNECTION | KOB |
| A28. | YT20V00002F1 | [1] | VALVE | KOBASSY |
| A29. | 2444R1120D090 | [2] | HOSE | KOB |
| A31. | LC52S00011P1 | [4] | SENSOR | KOBPRESS (L.P.) Superseded by part number: LC52S00019P1 |
| A31-2. | ZD12P01100 | [1] | O-RING | KOB |
| A32. | HH55Q06004G3 | [1] | TEE | KOB |
| A34. | HH25R04004G5 | [3] | HYD CONNECTOR | KOB |
| A35. | PF21V00004P1 | [1] | CHECK VALVE | KOBASSY |
| A36. | 2444Z4252 | [1] | HYD CONNECTOR | KOB |
| A37. | YX64H01038P1 | [1] | ELBOW | KOB |
| A38. | 2444Z3802 | [1] | HYD CONNECTOR | KOB |
| A39. | 2444Z2336 | [1] | HYD CONNECTOR | KOB |
| A40. | 2444R596D1 | [1] | ELBOW | KOB |
| A41. | 2444Z2461 | [5] | TEE | KOB |
| A42. | 2444T3402 | [2] | HYD CONNECTOR | KOB Superseded by part number: HH55V06006G3 |
| . . | YT64H00043F1 | [1] | CONTROL LINES, VALVE | |
| B1. | ZX23M06330 | [1] | HOSE | KOB |
| B2. | ZX22M06310 | [1] | HOSE | KOB |
| B3. | 2418Z1333D35 | [2] | PROTECTIVE SLEEVE,19.5mm ID x 23.8mm OD x 1800mm Length | KOBProtective Plastic |
| B7. | ZC48X24014 | [1] | CLIP | KOBClamp, Double -- Ø24x85mm Long |
| B8. | ZS18C12020 | [1] | SCREW,Hex, M12 x 20mm | KOB |
| B9. | ZW16H12000 | [1] | WASHER | KOB |
| B17. | PY01P01043D8 | [3] | CABLE TIE,102mm L | KOB |
| B18. | 2418Z1333D4 | [1] | PROTECTIVE SLEEVE,19.5mm ID x 23.8mm OD x 500mm Length | KOB |
