神钢零件查询(K935) - EXCAVATOR SUPPLEMENT ASN LU00154 (1/76-12/03) (02-029) - GUARD ASSY (FOR NORTH AMERICA, ALASKA) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
116 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100X1785F4 | [1] | GUARD ASSY | |
| 3. | 24100N3313F1 | [1] | GUARD ASSY, SEE FIG. 02-044 | |
| 4. | 2414P2539 | [1] | COVER | |
| 5. | 2414P2425 | [1] | COVER | COVER |
| 6. | 2414P3634 | [1] | GUARD | |
| 7. | 2414P2535 | [1] | COVER | |
| 8. | 2427P1685 | [1] | DUCT | |
| 9. | 2414P2536 | [1] | COVER | |
| 10. | 2414P2557 | [1] | COVER | |
| 11. | 2414P2537 | [1] | COVER | |
| 12. | 2414P2538 | [1] | COVER | |
| 13. | 2414P2190 | [1] | COVER | |
| 14. | 2416Z218D11 | [1] | SEAT, RUBBER, Serial Range: LU.0134--LU.0145 | |
| . . | 2416Z218D11 | [3] | SEAT, RUBBER, Start Serial: LU.0I46- | |
| 15. | 21Z1 | [3] | WRENCH | KOBKEY, LOCK PADLOCK, WITH KEYS |
| 18. | 2414P2423D1 | [1] | COVER | COVER |
| 19. | 2414P2423D2 | [1] | COVER | |
| 20. | 2416P6207 | [1] | BRACKET | |
| 21. | 2416P6206 | [1] | BRACKET | BRACKET |
| 22. | 2427P1941D1 | [1] | DUCT | |
| 23. | 2427P194102 | [1] | DUCT | |
| 24. | 2427P1679 | [2] | DUCT | |
| 25. | 2416P11393 | [1] | BRACKET | |
| 26. | 2416P5987D2 | [1] | BRACKET | |
| 27. | 2416P5987D1 | [1] | BRACKET | |
| 26. | 2416T5329D2 | [1] | BRACKET | |
| 29. | 2416T5329D1 | [1] | BRACKET | |
| 30. | 2416T5330 | [2] | BRACKET | |
| 31. | 2427P1681 | [1] | DUCT | DUCT |
| 32. | 2427P1682 | [1] | DUCT | |
| 33. | ZS16C12030 | [20] | CAPSCREW M12x1.75x30mm | CAPSCREW M12x1.75x30mm |
| 34. | ZN16C12010 | [20] | NUT | KOB Superseded by part number: ZN18C12010 |
| 35. | ZW26X12000 | [79] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 36. | ZW16X12000 | [75] | WASHER | KOBID 12 x OD 24 x Th 2.3mm |
| 37. | ZS18C10015 | [46] | BOLT,Hex, M10 x 15mm | KOBM10x1.50x15mm Superseded by part number: ZS18C10016 |
| 38. | ZW26X10000 | [32] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 39. | ZW16X10000 | [46] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 40. | ZS16C12025 | [42] | CAPSCREW M12x1.75x25mm | CAPSCREW M12x1.75x25mm |
| 41. | ZS16C12040 | [21] | SCREW | KOBM12x1.75x40mm Superseded by part number: ZS18C12040, 77276427 |
| 42. | ZS18C12020 | [32] | SCREW,Hex, M12 x 20mm | KOBM12x1.75x20mm |
| 43. | 2427P1680D1 | [1] | DUCT | DUCT |
| 44. | 2427P1680D2 | [1] | DUCT | |
| 45. | 2414P2559 | [1] | COVER | |
| 46. | 2414P2560 | [1] | COVER | |
| 47. | 2406N455 | [1] | HANDRAIL | |
| 48. | 2416Z218D9 | [2] | SEAT, RUBBER | |
| 49. | R27T0013D2 | [2] | LATCH | KOB |
| 57. | 24100J5734F3 | [1] | GUARD ASSY, SEE FIG, 02-044 | |
| 59. | 24100J5735F3 | [1] | GUARD ASSY, SEE FIG. 02-035 | |
| 61. | 2427J2011 | [1] | BOX, TOOL | |
| 61-24. | 2427T328 | [4] | LOCK | |
| 61-25. | ZS18C05012 | [4] | SCREW,Hex, M5 x 12mm | KOBM05x0.8x12mm |
| 61-26. | ZN18C05004 | [8] | NUT | KOBM05x0.8mm |
| 61-27. | ZW26X05000 | [8] | LOCK WASHER | KOBLock -- ID 05 x OD 09 x Th 1.3mm |
| 63. | 2414N3167 | [1] | COVER | |
| 64. | 2427R615 | [1] | INSULATOR | |
