现代零件查询R500LC-7 TRAVEL MOTOR (2/2, TYPE 3, 4)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
957 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
TRAVEL MOTOR ASSY
|
|
| -1. |
@
|
[1] |
TRAVEL MOTOR UNIT
|
|
| 1. |
39QB-41110
|
[1] |
CASING-SHAFT
|
|
| 2. |
39Q6-41120
|
[1] |
PLUG
|
|
| K3. |
P220-430231
|
[1] |
PLUG
|
|
| K4. |
39Q8-41120
|
[1] |
SEAL-OIL
|
|
| 5. |
S602-100001
|
[1] |
RING-RETAINING,C TYPE
|
|
| NK6. |
39Q8-41150
|
[1] |
PISTON
|
|
| NK7. |
39Q8-41160
|
[1] |
SEAL-PISTON
|
|
| 8. |
39Q8-41171
|
[1] |
SHAFT
|
|
| 9. |
39Q8-41180
|
[1] |
BEARING-CYL.ROLLER
|
|
| 10. |
39Q8-41191
|
[1] |
BEARING-NEEDLE
|
|
| 11. |
S601-055001
|
[1] |
RING-RETAINING,C TYPE
|
|
| 12. |
39Q8-41210
|
[1] |
PLATE-THRUST
|
|
| 13. |
39Q8-41220
|
[1] |
BALL-STEEL
|
|
| 14. |
39Q8-41230
|
[2] |
PIVOT
|
|
| 15. |
39QB-41130
|
[1] |
PLATE-SWASH
|
|
| NK16. |
39Q8-41270
|
[1] |
BLOCK-CYLINDER
|
|
| K17. |
39Q8-41280
|
[9] |
SPRING
|
|
| K18. |
39Q8-41300
|
[1] |
GUIDE-BALL
|
|
| K19. |
39Q8-41310
|
[1] |
PLATE-RETAINER
|
|
| K20. |
39Q8-41320
|
[9] |
PISTON ASSY
|
|
| K20. |
39Q8-41321
|
[9] |
PISTON ASSY
|
|
| 21. |
39Q8-41351
|
[6] |
PLATE-FRICTION
|
|
| 22. |
39Q8-41360
|
[7] |
PLATE-SEPARATE
|
|
| 23. |
39QA-41370
|
[1] |
PISTON-PARKING
|
|
| K24. |
39Q8-41380
|
[1] |
D-RING
|
|
| K25. |
39Q8-41390
|
[1] |
D-RING
|
|
| 26. |
39Q8-41400
|
[1] |
PLATE-VALVE
|
|
| 26. |
39Q8-41600
|
[1] |
PLATE-VALVE
|
|
| -2. |
@
|
[1] |
TRAVEL REDUCTION GEAR
|
|
| K. |
39Q8-41140
|
[1] |
PLUG KIT
|
|
| K. |
39Q8-41250
|
[1] |
ROTARY KIT
|
|
| K. |
39Q8-41260
|
[1] |
CYLINDER BLOCK KIT
|
|
| K. |
39Q8-41290
|
[1] |
RETAINER KIT
|
|
| K. |
39Q8-41560
|
[1] |
O-RING KIT
|
|
| K. |
39Q8-41570
|
[1] |
D-RING KIT
|
|
