| 1. |
84429995
|
[1] |
FAN
|
ZED
(25, 26) Superseded by part number: 84074638, 84275427, 86500036, 87695582
|
| 2. |
80140182
|
[1] |
WASHER
|
ZED
Superseded by part number: 140182
|
| 3. |
84800683
|
[1] |
PLATE
|
ZED
|
| 3. |
84400011
|
[1] |
SUPPORT
|
ZED
|
| 3. |
84400009
|
[1] |
SUPPORT
|
ZED
|
| 3. |
84429805
|
[1] |
SUPPORT
|
ZED
|
| 4. |
80362786
|
[1] |
LOCKING TAB
|
ZED
Superseded by part number: 362786
|
| 5. |
80445394
|
[1] |
RIVET
|
ZED
Superseded by part number: 151-573
|
| 6. |
80362785
|
[4] |
WASHER
|
ZED
Superseded by part number: 362785
|
| 7. |
84058832
|
[1] |
CLIP
|
ZED
, Serial Range: -C455
|
| 7. |
84818442
|
[1] |
CLAMP,13.3mm ID, 6.7mm Bolt Hole, P Type
|
ZED
, Start Serial: D456
|
| 8. |
89839372
|
[1] |
CLAMP
|
ZED
, Serial Range: -C455 Superseded by part number: 9839372
|
| 8. |
86010402
|
[1] |
CLAMP,12.7mm, Coat, 10.3mm Bolt Hole, P Type
|
NH
, Start Serial: D456
|
| 9. |
89824326
|
[1] |
WASHER
|
ZED
5 MM Superseded by part number: 9824326
|
| 10. |
80323597
|
[1] |
STRAP
|
ZED
, Serial Range: -C455 Superseded by part number: 14560287
|
| 10. |
86566990
|
[1] |
CABLE TIE,292mm OAL x 4.8mm W
|
ZED
CABLE STRAP, Start Serial: D456
|
| 11. |
84053243
|
[1] |
PLATE
|
ZED
RH, Serial Range: -C455
|
| 11. |
84400168
|
[1] |
PLATE
|
ZED
, Serial Range: -C455
|
| 12. |
84078904
|
[1] |
PLATE
|
ZED
LH, Serial Range: -C455
|
| 12. |
84400166
|
[1] |
PLATE
|
ZED
LH, Serial Range: -C455
|
| 13. |
80043127
|
[1] |
SCREW,M8 x 25mm
|
ZED
M8 x 25 Superseded by part number: 43127
|
| 14. |
84072857
|
[1] |
WIRE HARNESS
|
ZED
|
| 14. |
84072855
|
[1] |
WIRE HARNESS
|
ZED
|
| 15. |
80120100
|
[1] |
BOLT,M6 x 1 x 20mm
|
ZED
Superseded by part number: 120100
|
| 16. |
84053328
|
[1] |
PLATE
|
ZED
|
| 16. |
84053242
|
[1] |
PLATE
|
ZED
|
| 17. |
84400036
|
[2] |
BRACKET
|
ZED
|
| 18. |
86512439
|
[1] |
CARRIAGE BOLT,M6 x 16mm, Cl 8.8
|
NH
|
| 19. |
80322358
|
[1] |
LOCK WASHER
|
ZED
8 MM Superseded by part number: 322358
|
| 20. |
86629542
|
[1] |
NUT,M8 x 1.25, Cl 8.8
|
ZED
|
| 21. |
80322357
|
[1] |
LOCK WASHER,Belleville, M6
|
ZED
Superseded by part number: 322357
|
| 22. |
15896221
|
[14] |
NUT,Hex, M6, 5.20mm High, Cl 10
|
ZED
Superseded by part number: 86500688
|
| 23. |
80401266
|
[1] |
STRIP-GASKET
|
ZED
Superseded by part number: 401266
|
| 24. |
80401278
|
[1] |
SEAL
|
ZED
L= 2.550 M
|
| 25. |
334588
|
[1] |
TERMINAL CONNECTOR,1.00 - 2.50mm
|
ZED
|
| 26. |
334698
|
[1] |
TERMINAL CONNECTOR,Female
|
ZED
Superseded by part number: 87680259
|
| 27. |
412152
|
[1] |
NUT,M6 x 1, Cl 8.8
|
ZED
|
| 28. |
86508568
|
[4] |
BOLT,Hex, M6 x 1 x 16mm, Cl 8.8
|
NH
|
