纽荷兰零件查询(E70SR) - MIDI CRAWLER EXCAVATOR ASN YT04-07175 (02-011) - HYD LINES, LOW New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
407 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT02H00024F1 | [1] | HYD LINES, LOW | |
| A1. | YT02H01134P1 | [1] | TUBE | KOB |
| A2. | YT02H01133P1 | [1] | TUBE | KOB |
| A3. | YT02H01136P1 | [1] | TUBE | KOB |
| A4. | YT02H01135P1 | [1] | TUBE | KOB |
| A5. | YT02H01132P1 | [1] | TUBE | KOB |
| A6. | YT02H01131P1 | [1] | TUBE | KOB |
| A7. | YT02H01124P1 | [1] | TUBE | KOB |
| A8. | YT02H01123P1 | [1] | TUBE | KOB |
| A9. | YT02H01125P1 | [1] | TUBE | KOB |
| A10. | ZX23M04135 | [2] | HOSE | KOB |
| A11. | ZA23B18000 | [2] | HYD CONNECTOR | KOB |
| A12. | 2420Z1224D4 | [4] | HOSE | KOB |
| A13. | PY01P01043D3 | [4] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| A14. | 2432P2657 | [2] | CLAMP | KOB |
| A15. | 2432T5305 | [2] | CLAMP | KOB |
| A16. | LE02H01031P1 | [2] | SPACER | KOB |
| A17. | 2418T24324D1 | [2] | SPACER | KOB |
| A18. | ZS18C08040 | [4] | SCREW,Hex, M8 x 40mm | KOBM08x1.25x40mm |
| A19. | ZW26X08000 | [4] | LOCK WASHER | KOBLock Superseded by part number: 83990583 |
| A20. | ZW16X08000 | [4] | WASHER | KOB |
| . . | YT19H00018F1 | [1] | HYD LINES, SWIVEL | |
| B1. | ZA23F18008 | [4] | HYD CONNECTOR | KOB |
| B2. | ZA23F10004 | [1] | HYD CONNECTOR | KOB |
| B3. | YT19H01008P1 | [1] | TEE | KOB |
| B4. | ZE72X06000 | [2] | PLUG | KOB |
| B5. | ZD12P01800 | [4] | O-RING | KOB |
| B6. | ZD12P01400 | [1] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| B7. | ZD12P01100 | [1] | O-RING | KOB |
| . . | YT12H00001F1 | [1] | HYD LINES, PROPEL | |
| C1. | PY02H01001P1 | [4] | HYD CONNECTOR | KOB |
| C2. | ZA24F15006 | [2] | CONNECTION | KOB |
| C3. | ZH22X04000 | [2] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB |
