纽荷兰零件查询(E70SR) - MIDI CRAWLER EXCAVATOR ASN YT04-07175 (01-015) - TANK ASSY, FUEL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
501 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT20P00010F2 | [1] | TANK ASSY, FUEL | |
| A2. | 2446R326 | [1] | FILTER STRAINER | KOB |
| A3. | PW20P01044P1 | [1] | CAP | KOB |
| A4. | PH20P01003P1 | [1] | PLUG | KOBASSY |
| A5. | LE20P01017P1 | [1] | HOSE ASSY. | KOB |
| A6. | LE20P01012P1 | [2] | CLAMP | KOB |
| A7. | LE20P01014P1 | [1] | BALL | KOB |
| A8. | 2418T8245 | [1] | PACKING | KOB Superseded by part number: YN20P01147P1 |
| A9. | YW21C01057DD | [1] | WEATHERSTRIP | KOB |
| A10. | PY01P01019DF | [1] | WEATHERSTRIP | KOB |
| A11. | YT21C01297D1 | [1] | WEATHERSTRIP | KOB |
| A12. | YT20P00013P1 | [1] | FUEL TANK | KOB |
| . . | YT20P00011F1 | [1] | TANK INSTAL, FUEL | |
| B1. | ZS18C16030 | [4] | SCREW,Hex, M16 x 30mm | KOBCAP |
| B2. | ZW16H16000 | [4] | WASHER | KOB |
| B3. | YT20P01023P1 | [1] | BRACKET | KOB |
| B4. | ZM32C12025 | [2] | BOLT | KOBSEMS |
| B5. | YN52S00034F1 | [1] | SENSOR | KOBASSY, LEVEL |
| B6. | 2418T9962 | [1] | PACKING | KOB |
| B7. | ZS31C05012 | [5] | BOLT,Phillips Drive, Pan HD, M5 x 12mm | KOBMACHINE |
| B8. | ZW26X05000 | [5] | LOCK WASHER | KOBLOCK |
| B9. | YT21C01104P2 | [1] | RUBBER | KOB |
| B10. | YN21C01757D1 | [1] | SHIM | KOB(1.2) |
| B11. | YN21C01757D2 | [1] | SHIM | KOB(2.0) |
