现代零件查询R500LC-7 QUICK CLAMP(HOOK TYPE, #0155-)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
293 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
31NB-96810
|
[1] |
QUICK CLAMP ASSY
|
|
| 1. |
XKBN-00257
|
[1] |
BODY
|
|
| 2. |
XKBN-00258
|
[1] |
HITCH
|
|
| 3. |
XKBN-00259
|
[1] |
CYLINDER ASSY
|
|
| 4. |
XKBN-00260
|
[1] |
PIN-SAFETY
|
|
| 5. |
XKBN-00246
|
[1] |
PIN-SNAP
|
|
| 6. |
XKBN-00261
|
[1] |
PIN-HITCH
|
|
| 7. |
XKBN-00262
|
[1] |
PIN-FRAME
|
|
| 8. |
XKBN-00009
|
[3] |
NIPPLE-GREASE
|
|
| 9. |
XKBN-00263
|
[1] |
PIN-CYLINDER
|
|
| 10. |
XKBN-00167
|
[4] |
RING-SNAP
|
|
| 11. |
XKBN-00264
|
[2] |
PIN-BRACKET
|
|
| 12. |
XKBN-00265
|
[2] |
BOLT-HEX
|
|
| 13. |
XKBN-00080
|
[4] |
NUT-HEX
|
|
| 14. |
XKBN-00112
|
[2] |
HOSE-PROTECTOR
|
|
| 15. |
XKBN-00016
|
[2] |
ELBOW-90
|
|
| 16. |
XKBN-00266
|
[1] |
WIRE ASSY
|
|
| 17. |
XKBN-00116
|
[1] |
LATCH & SPRING
|
|
| 18. |
XKBN-00218
|
[2] |
RING-SNAP
|
|
