久保田零件查询T04000 HYDRAULICS 2 HYDRAULIC SYSTEMEPC Kubota online
广数供应链运营团队, 15 02月, 2025，浏览：
365 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 001. |
6640436600
|
[1] |
ASSY CAP CYLINDER
|
2.5740(lbs); 1.170
|
| 002. |
9631901410
|
[1] |
CAP CYLINDER
|
2.2440(lbs); 1.020
|
| 003. |
0481150550
|
[1] |
O RING
|
0.0044(lbs); 0.002
|
| 004. |
6671136440
|
[2] |
BOLT
|
0.0990(lbs); 0.045
|
| 005. |
0451250120
|
[2] |
WASHER SPRING
|
0.0066(lbs); 0.003
|
| 006. |
6661136413
|
[1] |
STAY
|
0.3080(lbs); 0.140
|
| 006. |
H666036410
|
[1] |
STAY
|
0.3080(lbs); 0.140
|
| 007. |
0112051025
|
[2] |
BOLT
|
0.0000(lbs); 0.000
|
| 008. |
6721136420
|
[1] |
RING
|
0.0066(lbs); 0.003
|
| 009. |
0631125040
|
[1] |
PLUG
|
0.1980(lbs); 0.090
|
| 010. |
6661136420
|
[1] |
GASKET
|
0.0132(lbs); 0.006
|
| 011. |
6721136410
|
[1] |
PISTON HYDRAULIC
|
1.2100(lbs); 0.550
|
| 012. |
0481008500
|
[1] |
O RING
|
0.0110(lbs); 0.005
|
| 013. |
6659136640
|
[1] |
ROD HYDRAULIC PISTON
|
0.6820(lbs); 0.310
|
| 014. |
6659136650
|
[1] |
ARM OIL PRESSURE
|
1.7600(lbs); 0.800
|
| 015. |
6659136660
|
[1] |
PIN ARM
|
0.0990(lbs); 0.045
|
| 016. |
6659136670
|
[1] |
PLATE LOCK
|
0.0220(lbs); 0.010
|
| 017. |
6659136680
|
[1] |
WASHER LOCK
|
0.0044(lbs); 0.002
|
| 018. |
0105050612
|
[2] |
BOLT
|
0.0110(lbs); 0.005
|
| 019. |
6662136750
|
[1] |
PLATE HYDRAULIC ARM
|
0.7480(lbs); 0.340
|
| 020. |
0115350822
|
[2] |
BOLT
|
0.0242(lbs); 0.011
|
| 020. |
6721136610
|
[2] |
BOLT
|
0.0330(lbs); 0.015
|
| 021. |
0411150080
|
[2] |
WASHER TONGUED
|
0.0022(lbs); 0.001
|
| 022. |
0401350100
|
[2] |
WASHER PLAIN
|
0.0088(lbs); 0.004
|
| 023. |
9631901422
|
[1] |
SPOOL SUB
|
0.1540(lbs); 0.070
|
| 024. |
0481100120
|
[1] |
O RING
|
0.0022(lbs); 0.001
|
| 025. |
0481100160
|
[1] |
O RING
|
0.0022(lbs); 0.001
|
| 026. |
0481100100
|
[1] |
O RING
|
0.0022(lbs); 0.001
|
| 026. |
0481005110
|
[1] |
O RING
|
0.0022(lbs); 0.001
|
| 027. |
9631901430
|
[1] |
WASHER
|
0.0044(lbs); 0.002
|
| 028. |
9631901440
|
[1] |
SPRING
|
0.0044(lbs); 0.002
|
| 029. |
9631901450
|
[1] |
GRIP
|
0.0880(lbs); 0.040
|
| 030. |
0541100520
|
[1] |
PIN SPRING
|
0.0044(lbs); 0.002
|
