神钢零件查询(K935) - EXCAVATOR SUPPLEMENT ASN LU00154 (1/76-12/03) (09-029) - PARTS,TRANSPORT P/N LU764-001 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
207 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LU764-001 | [1] | PARTS, TRANSPORT | |
| 1. | 24100P559F1 | [1] | PLUG | |
| 1-1. | ZE91T08000 | [2] | CAP | KOB1/2" PT |
| 1-2. | ZH22F04000 | [1] | HYD CONNECTOR | KOB |
| 1-3. | 2444T1329D6 | [12] | PLUG | KOB Superseded by part number: ZF83H35000 |
| 1-4. | 2444T1329D5 | [2] | PLUG | KOB Superseded by part number: ZF86P28000 |
| 2. | 24100T108F1 | [2] | PLUG | |
| 2-1. | ZE82T08000 | [1] | PLUG | KOB1/2" PT |
| 2-2. | 2444T1339 | [1] | PLUG | |
| 2-3. | 2444T1338D6 | [1] | PLUG | KOB Superseded by part number: ZF96N35000, ZF86P35000 |
| 2-4. | ZF93N35000 | [1] | NUT | KOB |
| 3. | 24100T106F1 | [2] | PLUG | |
| 3-1. | 2444T1338D6 | [2] | PLUG | KOB Superseded by part number: ZF96N35000, ZF86P35000 |
| 3-2. | ZF93N35000 | [2] | NUT | KOB |
| 4. | 24100P557F2 | [1] | PLUG | |
| 4-l. | 2444T1329D5 | [4] | PLUG | KOB Superseded by part number: ZF86P28000 |
| 4-2. | 2444T1329D6 | [2] | PLUG | KOB Superseded by part number: ZF83H35000 |
| 4-3. | ZF93N35000 | [4] | NUT | KOB |
| 4-4. | ZF93N28000 | [2] | TUBE NUT | KOB Superseded by part number: ZA93N28000 |
| 5. | 24100P554F2 | [1] | PLUG | |
| 5-1. | 2444T1338D5 | [2] | PLUG | |
| 5-2. | ZF93N28000 | [2] | TUBE NUT | KOB Superseded by part number: ZA93N28000 |
| 6. | 24100T107F1 | [1] | PLUG | |
| 6-1. | 2444T1329D5 | [2] | PLUG | KOB Superseded by part number: ZF86P28000 |
