纽荷兰零件查询(E70SR) - MIDI CRAWLER EXCAVATOR ASN YT04-07175 (01-028[01]) - CONTROL LINES, REMOTE, P/N YT68H00044F2 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
263 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT68H00044F2 | [1] | CONTROL LINES, REMOTE | |
| A1. | 2420R349D205 | [1] | HOSE | KOB |
| A2. | 2444R1119D190 | [1] | HOSE | KOB |
| A3. | 2420R349D145 | [1] | HOSE | KOB Superseded by part number: HX21E04145DX |
| A4. | 2444R1119D140 | [1] | HOSE | KOB |
| A5. | YT68H01011D1 | [1] | HOSE | KOB |
| A6. | YT68H01011D2 | [1] | HOSE | KOB |
| A7. | YT68H01010D3 | [1] | HOSE | KOB |
| A8. | YR68H01031D4 | [1] | FLEXIBLE HOSE | KOB |
| A9. | YR68H01029D1 | [1] | HOSE | KOB |
| A10. | YT68H01012D2 | [1] | HOSE | KOB |
| All. | YR68H01029D3 | [1] | HOSE | KOB |
| A12. | YT68H01012D4 | [1] | HOSE | KOB |
| A13. | PY01P01043D3 | [2] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| A14. | PH03M01250P1 | [2] | BOOT | KOB |
| A16. | ZS28C06025 | [8] | SCREW,Hex Socket Head, M6 x 25mm | KOBCAP |
| A17. | ZW16X06000 | [8] | WASHER | KOB Superseded by part number: 86588450 |
| A18. | ZC46X29011 | [1] | CLIP | KOB |
| A19. | ZS18C10020 | [2] | SCREW,Hex, M10 x 20mm | KOBCap |
| A20. | ZW16H10000 | [2] | WASHER | KOB |
| A21. | ZH22X04000 | [8] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB |
| A22. | 2444Z2337 | [2] | HYD CONNECTOR | KOB |
| A23. | PU13E01010DJ | [1] | TUBE | KOB |
| A24. | 2444R1119D260 | [1] | HOSE | KOB |
| A25. | YT68H01003D2 | [1] | GROMMET | KOB |
| A26. | YT68H01003D1 | [1] | GROMMET | KOB |
| A27. | ZC48X14011 | [1] | CLIP | KOB |
| A28. | HH25X04004G2 | [2] | HYD CONNECTOR | KOB |
| A29. | YR68H01016D1 | [2] | HOSE | KOB |
| A30. | PU13E01002D1 | [1] | TUBE | KOB |
| A31. | PX30V00043F2 | [2] | HYDRAULIC VALVE | KOBASSY, PILOT |
| . . | YT64H00044F2 | [1] | CONTROL LINES, BLOCK | |
| B1. | 2420R349D100 | [1] | HOSE | KOB Superseded by part number: HX21E04100DX |
| B2. | 2420R349D050 | [1] | HOSE,500.00 mm | KOB |
| B3. | 2420R349D090 | [2] | HOSE,6.35mm ID x 900mm L | KOB |
| B4. | ZH32X04000 | [7] | 90 ELBOW,Male, 30° Fl, PF 1/4" x PF 1/4", O-Ring | KOB |
| B5. | LC52S00011P1 | [3] | SENSOR | KOBPRESS (L.P.) Superseded by part number: LC52S00019P1 |
| B5-2. | ZD12P01100 | [1] | O-RING | KOB |
| B6. | YT64H01032P1 | [1] | BLOCK | KOB |
| B7. | YT64H01031P1 | [1] | BRACKET | KOB |
| B8. | ZS18C10025 | [2] | SCREW,Hex, M10 x 25mm | KOB |
| B9. | ZS18C08025 | [2] | SCREW,Hex, M8 x 25mm | KOBCAP |
| B11. | ZW16H08000 | [2] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
| B12. | 2444Z2894 | [1] | 90 ELBOW | KOB |
| B13. | 2444Z2525 | [1] | HYD CONNECTOR | KOB |
| B14. | YT20V00002F1 | [1] | VALVE | KOBASSY |
| B15. | HH35X04004G3 | [1] | 90 ELBOW | KOB |
| B16. | HH25R04004G5 | [1] | HYD CONNECTOR | KOB |
| B17. | ZE72X04000 | [1] | PLUG | KOB |
| . . | YT06H00022F6 | [1] | CONTROL LINES, MAIN | |
| C2. | HH55Q04004G1 | [3] | TEE,1/4" ORB x 1/4" JIC x 1/4" JIC | KOB |
| C4. | 2444T2524 | [4] | HYD CONNECTOR | KOB |
| C6. | HH25R06004G2 | [1] | CONNECTION | KOB |
| C7. | 2444R1120D100 | [1] | HOSE | KOB |
| C8. | 2444R1120D120 | [1] | HOSE | KOB |
| C9. | 2444R1120D070 | [1] | HOSE | KOB |
| C10. | 2444R1120D160 | [1] | HOSE | KOB |
| C11. | 2420R349D075 | [2] | HOSE | KOB Superseded by part number: 2444R3019D3 |
| C12. | 2420R349D105 | [1] | HOSE,1050.00 mm | KOB |
| C15. | HH25R04004G3 | [1] | CONNECTION | KOB |
| C17. | PY01P01043D6 | [2] | CABLE TIE,4.80mm W x 383mm L | KOB |
| C18. | ZH42X04000 | [2] | 45 ELBOW,Male, 30° Fl, PF 1/4" x PF 1/4", O-Ring | KOB45 |
| C20. | ZH32X06000 | [1] | 90 ELBOW,Male, 30° Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 |
| C21. | ZH32X04006 | [3] | 90 ELBOW,Male, 30° Fl, PF 1/4" x PF 3/8", O-Ring | KOB |
| C23. | YT21V00002P1 | [1] | CHECK VALVE | KOBASSY |
| C26. | 2444Z3541 | [1] | CONNECTION | KOB Superseded by part number: 2444Z3759 |
| C27. | HH25X04004G3 | [1] | CONNECTION | KOB |
| C28. | HH55Q06004G3 | [1] | TEE | KOB |
| C29. | 2444R1120D090 | [2] | HOSE | KOB |
| C35. | PF21V00004P1 | [1] | CHECK VALVE | KOBASSY |
| C36. | 2444Z4252 | [1] | HYD CONNECTOR | KOB |
| C37. | YX64H01038P1 | [1] | ELBOW | KOB |
| C38. | 2444Z3802 | [1] | HYD CONNECTOR | KOB |
| C39. | 2444Z2336 | [1] | HYD CONNECTOR | KOB |
| C40. | 2444R596D1 | [1] | ELBOW | KOB |
| C41. | 2444Z2461 | [5] | TEE | KOB |
| C42. | 2444T3402 | [1] | HYD CONNECTOR | KOB Superseded by part number: HH55V06006G3 |
