神钢零件查询(K935) - EXCAVATOR SUPPLEMENT ASN LU00154 (1/76-12/03) (03-003) - CONTROL LOADING Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
632 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N2152F1 | [1] | CONTROL, LOADING, Serial Range: LU.0086,0096--LU.0107 | |
| . . | 24100N2152F2 | [1] | CONTROL, LOADING, Start Serial: LU.0108- | |
| 1. | 24100N1154F2 | [1] | PEDAL ASSY, SEE FIG. 03-013 | |
| 2. | 2420R349D430 | [1] | HOSE | KOB |
| 3. | 2420R349D470 | [1] | HOSE 4700mm Long (185-1/32 in) | HOSE 4700mm Long (185-1/32 in) |
| 4. | 2420R349D040 | [1] | HOSE,6.35mm ID x 400mm L | KOB1/4" PF, 400mm Long (15-3/4 in) |
| 5. | ZH32Z04000 | [3] | ELBOW | KOB90° -- (1/4" PT - 1/4" PT), (Incls. O-Ring ZD12P01100) |
| 6. | ZH31K08004 | [1] | ELBOW | KOB90° |
| 7. | ZH21K08004 | [1] | HYD CONNECTOR | KOB |
| 8. | ZX15K08040 | [1] | PLASTIC-RUBBER TUBE | KOB |
| 9. | 2427R322D2 | [1] | MAT, FLOOR, Serial Range: LU.0086,0096--LU.0107 | |
| 10. | ZH22Z04000 | [3] | HYD CONNECTOR | KOB1/4"PTx1/4"PFx37mm Long |
| 11. | 2427R340D2 | [1] | MAT, FLOOR, Serial Range: LU.0086,0096--LU.0107 | |
| 12. | 2427R560D2 | [1] | MAT, FLOOR, Serial Range: LU.0108--LU.0107 | |
| 13. | 2427R561D2 | [1] | MAT, FLOOR, Start Serial: LU.0108- | |
