| . . | 24100J7393F1 | [1] | CONTROL ASSY, Serial Range: LU.0122--LU.0145 | |
| . . | 24100J7393F3 | [1] | CONTROL ASSY, Start Serial: LU.0146- | |
| 1. | 24100X2038F1 | [1] | REMOTE-CONTROL ASSY, SEE FIG. 03-010, Serial Range: LU.0122--LU.0145 | |
| 2. | 2448U229F1 | [1] | SEAT | KOB, Serial Range: LU.0122--LU.0145 |
| 2. | 2448U230F1 | [1] | SEAT, Start Serial: LU.0146- | SEAT, Start Serial: LU.0146- |
| 3. | 2416P7201 | [1] | STAND, SEAT, Serial Range: LU.0122--LU.0145 | STAND, SEAT, Serial Range: LU.0122--LU.0145 |
| 3. | 2416P7315 | [1] | STAND, SEAT, Start Serial: LU.0146- | |
| 4. | 2416N2771 | [1] | SUPPORT | SUPPORT |
| 4. | 2416N3192 | [1] | SUPPORT, Serial Range: LU.0146--LU.0145 | SUPPORT, Serial Range: LU.0146--LU.0145 |
| 5. | 2416P8514 | [1] | SUPPORT | KOB |
| 6. | 2416P7247 | [1] | SUPPORT | SUPPORT |
| 7. | 24100N2792F1 | [1] | SUPPORT ASSY | SUPPORT ASSY |
| 7-1. | 2416P7220 | [1] | SUPPORT | SUPPORT |
| 7-2. | 2414P2906 | [1] | COVER | KOB |
| 7-3. | 2414T1973 | [1] | COVER | COVER |
| 7-4. | ZS31C05014 | [6] | SCREW,Phillips Drive, Pan HD, M5 x 14mm | KOBM05x0.8x14mm |
| 7-5. | ZW11P05000 | [6] | WASHER | KOB Superseded by part number: ZW16P05000 |
| 8. | 24100N2790F2 | [1] | SUPPORT ASSY, Serial Range: LU.0122--LU.0145 | SUPPORT ASSY, Serial Range: LU.0122--LU.0145 |
| 8. | 24100N2790F3 | [1] | SUPPORT ASSY, Start Serial: LU.0146- | |
| 8-2. | 2414P2905 | [1] | COVER | KOB |
| 8-3. | 2414T1974 | [1] | COVER | |
| 8-4. | 2406P2491 | [1] | LEVER | KOB, Serial Range: LU.0122--LU.0145 |
| 8-5. | 2416Z332 | [1] | SHEET | KOB |
| 8-6. | 2417Z252 | [1] | SPRING | KOB |
| 8-7. | 2418T10552D4 | [1] | SPACER | KOB, Serial Range: LU.0122--LU.0145 |
| 8-8. | ZR36X00600 | [1] | SNAP RING | KOBE-Ring -- Shaft 06mm x OD 12mm |
| 8-9. | ZS31C05014 | [8] | SCREW,Phillips Drive, Pan HD, M5 x 14mm | KOBM05x0.8x14mm |
| 8-10. | ZW11P05000 | [8] | WASHER | KOB Superseded by part number: ZW16P05000 |
| 8-12. | 2406Z294D3 | [1] | GRIP | KOB |
| 8-16. | 2405U101D1612 | [2] | BUSHING | KOB |
| 8-17. | 2416N2801 | [1] | SUPPORT, Serial Range: LU.0122--LU.0145 | |
| 8-18. | 2432T1818 | [1] | CLAMP, Start Serial: LU.0146- | CLAMP, Start Serial: LU.0146- |
| 8-19. | ZS18C08016 | [2] | SCREW,Hex, M8 x 16mm | KOBM08x1.25x16mm, Start Serial: LU.0146- |
| 8-20. | ZW26X08000 | [2] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm, Start Serial: LU.0146- Superseded by part number: 83990583 |
| 8-21. | 2416T11070 | [1] | SEAT, RUBBER | SEAT, RUBBER |
| 8-22. | 2416N3193 | [1] | SUPPORT, Start Serial: LU.0146- | |
| 8-23. | 2406P2544 | [1] | LEVER | KOB, Start Serial: LU.0146- |
| 9. | 2406P1991 | [2] | LEVER, CONTROL | LEVER, CONTROL |
| 10. | 6Z1 | [2] | LEVER | KOB |
| 11. | 2420T3205 | [2] | ROD | |
| 12. | 2432T2855 | [2] | CLAMP | |
| 13. | 2419T2964 | [1] | PIN | PIN |
| 14. | 2418N2531 | [1] | PLATE, FLOOR | |
| 15. | 2422N763 | [1] | REWORK, DECK | |
| 16. | 2406P2395D1 | [1] | PEDAL | PEDAL |
| 17. | 2406P2395D2 | [1] | PEDAL | PEDAL |
| 18. | 2417R63 | [1] | SPRING | KOB |
| 19. | 2479Z932 | [1] | SWITCH | KOB |
| 20. | 2414Z265 | [1] | COVER | KOB |
| 21. | 2419T3603 | [1] | PIN | PIN |
| 22. | ZM11C10025 | [16] | BOLT | KOBM10x1.50x25mm (Incls. Lockwasher) Superseded by part number: ZM12C10025 |
| 23. | ZS18C08014 | [4] | SCREW,Hex, M8 x 14mm | KOBM08x1.25x14mm |
| 24. | ZS31C04030 | [2] | SCREW,Phillips Drive, Pan HD, M4 x 30mm | KOBM04x0.7x30mm |
| 25. | ZW26X08000 | [4] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 26. | ZW16K04000 | [2] | WASHER | KOBID 04 x OD 08 x Th 0.8mm |
| 27. | 2418T5373C2 | [4] | WASHER | KOBID 11 x OD 30 x Th 3.20mm Superseded by part number: 2418T12346 |
| 28. | ZW16X16000 | [5] | WASHER | KOBID 16 x OD 30 x Th 3.2mm |
| 30. | ZW16X08000 | [2] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 32. | ZN16C16010 | [2] | NUT | KOB |
| 33. | ZN16C04003 | [2] | NUT | KOBM04x0.7mm Superseded by part number: ZN18C04003 |
| 34. | ZN16C10008 | [2] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 35. | ZW26K10000 | [4] | LOCK WASHER | KOBLock -- ID 10 x OD 15.7 x Th 2.5mm Superseded by part number: 12581679 |
| 36. | ZS16C10030 | [2] | CAPSCREW | KOBSCREW M10x1.50x30mm Superseded by part number: ZS18C10030 |
| 37. | ZS23C10040 | [4] | SCREW,Hex Socket Head, M10 x 40mm | KOBM10x1.50x40mm |
| 38. | ZP15K02020 | [2] | SPLIT PIN | KOB |
| 39. | 2416P9192 | [2] | BRACKET | |
| 40. | 2414T1319 | [2] | COVER | |
| 41. | ZM11C08020 | [6] | BOLT | KOBM08x1.25x20mm (Incls. Lockwasher) Superseded by part number: ZM12C08020 |
| 42. | 2414T1054 | [8] | COVER | KOB |
| 43. | 2416Z253 | [8] | RUBBER SLEEVE | KOB |
| 44. | 2418T9226D1 | [4] | SPACER | KOB |
| 45. | ZS12C16100 | [4] | SCREW,Hex, M16 x 100mm | KOBM16x2.0x100mm |
| 46. | R16T0152D2 | [8] | WASHER | KOBFlat -- ID 17 x OD 30 x Th 3.2mm |
| 47. | ZN32C16015 | [4] | NUT | KOBM16x2.0mm |
| 48. | ZS17C16050 | [4] | CAPSCREW | CAPSCREW |
| 49. | ZW26X16000 | [4] | LOCK WASHER | KOBID 16 x OD 28 x Th 4.0mm |
| 50. | 24100N3670F1 | [1] | NOISE-INSULATOR ASSY | |
| 50-1. | 2422N764 | [1] | REWORK, DECK | |
| 50-2. | 2479N310 | [1] | INSULATOR | |
| 50-3. | 2420Z699 | [7] | GROMMET | KOB |
| 51. | 2427R583 | [1] | MAT, FLOOR | |
| 52. | 2427R584 | [1] | MAT, FLOOR | |
| 53. | 2427U287 | [1] | MAT, FLOOR | |
| 54. | 2427P2449 | [1] | REWORK, CAB | |
| 58. | 2418T12177 | [4] | PLATE | |
| 59. | 24100J10835F1 | [1] | REMOTE-CONTROL ASSY, SEE FIG. 03-036 LU.0146, Start Serial: — | |
