纽荷兰零件查询(E70SR) - MIDI CRAWLER EXCAVATOR ASN YT04-07175 (01-031) - PLATE GROUP, FLOOR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
786 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT03M00027F1 | [1] | PLATE GROUP, FLOOR | |
| A1. | YT03M01112P1 | [1] | SUPPORT | KOB |
| A2. | YT03M01113P1 | [1] | SUPPORT | KOB |
| A3. | YN03M01201P1 | [1] | COVER | KOB |
| A4. | YN03M01200P1 | [1] | COVER | KOB |
| A5. | YN03M01062P3 | [2] | COVER | KOB |
| A6. | YT03M01077P2 | [1] | SUPPORT | KOB |
| A7. | ZM22C08020 | [7] | BOLT | KOBSEMS |
| A8. | ZM22C10025 | [4] | BOLT | KOBSEMS |
| A9. | YT26M00021P1 | [1] | MAT | KOBFLOOR |
| B1. | YT03M00022P2 | [1] | PLATE ASSY. | KOBFLOOR |
| . . | YT03M00002F1 | [1] | PLATE ASSY. | KOBINSTAL, FLOOR |
| C1. | YT03M01049F1 | [2] | RUBBER MOUNTING | KOBASSY Superseded by part number: YT03M01232F1 |
| C2. | ZM22C10030 | [8] | BOLT | KOBM10x1.50x30mm (Incls. Washer & Lockwasher) |
| C3. | ZN18C16013 | [4] | NUT | KOB |
| C4. | ZW26X16000 | [4] | WASHER | KOB |
| C5. | ZW16H16000 | [4] | WASHER | KOB |
| C6. | YT03M01049F2 | [2] | RUBBER MOUNTING | KOBASSY |
