纽荷兰零件查询(E70SR) - MIDI CRAWLER EXCAVATOR ASN YT04-07175 (01-033) - MIRROR INSTAL, (P/N YT52C00007F1, YT52C00008F3) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
361 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT52C00008F3 | [1] | MIRROR | KOBINSTAL (STD/WITH ROOF & TRIPLE GUARD/LIGHT) |
| . . | YT52C00008F4 | [1] | MIRROR | KOBINSTAL (WITH FRONT UPP GUARD) |
| A1. | 2456Z253 | [1] | MIRROR | KOBBACK |
| A2. | YY02C01004P1 | [1] | STAY | KOBSTAY |
| A3. | ZN18C12010 | [4] | NUT | KOB |
| A4. | ZW16X12000 | [2] | WASHER | KOB |
| A5. | R16T0137D1 | [2] | WASHER | KOB |
| A7. | YY02C01001P1 | [1] | PLATE | KOBASSY, (F3 ONLY) |
| A8. | ZS18C10045 | [2] | SCREW,Hex, M10 x 45mm | KOBCAP, (F3 ONLY) |
| A9. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm, (F3 Only) |
| A10. | ZW16H10000 | [2] | WASHER | KOB(F3 ONLY) |
| A11. | YN02C01121P1 | [1] | MIRROR | KOB |
| A12. | ZM46C05016 | [3] | BOLT,Phillip, M5 x 0.8 x 15mm | KOBSEMS |
| A13. | YT50C01077P1 | [1] | BLOCK | KOBTAPPED |
| . . | YT52C00007F1 | [1] | MIRROR | KOBINSTAL |
| B1. | YY21C01270P1 | [1] | STAY | KOBSTAY |
| B3. | YT21C01349P1 | [1] | BRACKET | KOB |
| B6. | ZS18C10055 | [2] | SCREW,Hex, M10 x 55mm | KOBCAP |
| B8. | YT52C01007P1 | [1] | BLOCK | KOBTAPPED |
| B11. | ZW16X10000 | [2] | WASHER | KOB |
