凯斯零件查询(LBX332R) - BIG RECTANGULAR BALER ''ROTOR CUTTER'' (3/03-12/08) (01.11[01]) - FLYWHEEL Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
477 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84446517
|
[1] |
BALER FLYWHEEL
|
ZED
(2), Serial Range: -C667 Superseded by part number: 87660055, 375400, 87721200
|
| 1. |
87721200
|
[1] |
BALER FLYWHEEL
|
ZED
, Start Serial: D668
|
| 1. |
84446520
|
[1] |
BALER FLYWHEEL
|
ZED
(2), Serial Range: -C667 Superseded by part number: 87720102, 87660055, 86624979, 375400
|
| 1. |
87720102
|
[1] |
BALER FLYWHEEL
|
ZED
, Start Serial: D668
|
| 2. |
84058279
|
[1] |
SHEAR BOLT BUSHING,10.2mm ID x 31.7mm OD x 38mm L
|
ZED
, Serial Range: -C667
|
| 2. |
87695682
|
[1] |
SHEAR BOLT BUSHING,10.2mm ID x 31.7mm OD x 38mm L
|
ZED
, Start Serial: D668
|
| 2. |
84012933
|
[1] |
SHEAR BOLT BUSHING
|
ZED
, Serial Range: -C667 Superseded by part number: 82847706
|
| 3. |
84062387
|
[2] |
RING,55mm ID x 90mm OD x 12.85mm L
|
ZED
|
| 4. |
84032675
|
[1] |
HUB
|
ZED
Superseded by part number: 84800487
|
| 5. |
84062069
|
[1] |
DISC
|
ZED
|
| 6. |
80412677
|
[2] |
BOLT
|
ZED
Superseded by part number: 412677
|
| 7. |
84062386
|
[2] |
RING,55mm ID x 88.4mm OD
|
ZED
|
| 8. |
80853116
|
[2] |
BEARING ASSY
|
ZED
Superseded by part number: 87555831
|
| 9. |
80062161
|
[1] |
LUBE NIPPLE
|
ZED
Superseded by part number: 62161
|
| 10. |
83931335
|
[6] |
BOLT,Hex, M10 x 1.5 x 75mm, Cl 8.8
|
ZED
|
| 10. |
80536632
|
[6] |
BOLT
|
ZED
shear M10 x 60, Serial Range: -C667 Superseded by part number: 536632
|
| 10. |
86624979
|
[6] |
BOLT,Hex, M10 x 75mm, Cl 10.9
|
FAR
shear, Start Serial: D668
|
| 11. |
80100037
|
[1] |
NUT,M10 x 1.5, Class 8
|
ZED
Superseded by part number: 100037
|
| 12. |
84062070
|
[1] |
LOCKING PLATE
|
ZED
|
| 13. |
80440978
|
[1] |
ADJUSTING PLATE
|
ZED
THK.: 0.2 MM Superseded by part number: 440978
|
| 13. |
80140124
|
[1] |
ADJUSTING PLATE
|
ZED
THK.: 0.5 MM Superseded by part number: 140124
|
| 13. |
84062423
|
[1] |
SHIM
|
ZED
THK.: 1 MM
|
