凯斯零件查询(LBX332R) - BIG RECTANGULAR BALER ''ROTOR CUTTER'' (3/03-12/08) (05.01[01]) - SINGLE AXLE WITHOUT BRAKES Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
239 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84807493
|
[1] |
AXLE
|
ZED
(2-13)
|
| 1. |
84807494
|
[1] |
AXLE
|
ZED
|
| 2. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Shaft
|
| 3. |
84807624
|
[2] |
SEAL
|
ZED
Superseded by part number: 84521823
|
| 3. |
84807629
|
[2] |
SEALING RING
|
ZED
|
| 4. |
84100482
|
[2] |
RING
|
ZED
|
| 4. |
84100478
|
[2] |
RING
|
ZED
|
| 5. |
84100483
|
[2] |
BALL BEARING,75mm ID x 130mm OD x 33.25mm W
|
ZED
Superseded by part number: 26800210
|
| 5. |
89832270
|
[2] |
BEARING ASSY
|
ZED
Superseded by part number: 9832270
|
| 6. |
84100484
|
[2] |
RING
|
ZED
|
| 6. |
84041877
|
[2] |
SEALING RING
|
ZED
SEALRING
|
| 7. |
84100485
|
[2] |
BALL BEARING,60mm ID x 110mm OD x 29.75mm W
|
ZED
Superseded by part number: 87622924
|
| 7. |
84041879
|
[2] |
TAPERED BEARING
|
ZED
|
| 8. |
84100486
|
[2] |
NUT
|
ZED
|
| 8. |
84100479
|
[2] |
NUT
|
ZED
|
| 9. |
84041875
|
[2] |
PIN
|
ZED
|
| 10. |
84100487
|
[2] |
KIT
|
ZED
|
| 10. |
84041874
|
[2] |
DUST CAP
|
ZED
|
| 11. |
84041871
|
[16] |
BOLT
|
ZED
|
| 12. |
84045545
|
[16] |
WHEEL NUT
|
ZED
Superseded by part number: 84288019
|
| 13. |
84100480
|
[2] |
HUB
|
ZED
Superseded by part number: 87354761
|
| 13. |
84100476
|
[2] |
HUB
|
ZED
Superseded by part number: 87693636, 84100510, 84100512
|
