凯斯零件查询(LBX332R) - BIG RECTANGULAR BALER ''ROTOR CUTTER'' (3/03-12/08) (05.08[01]) - TANDEM AXLE WITH BRAKES Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
894 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84807542
|
[1] |
FRONT AXLE
|
ZED
(2-29)
|
| 1. |
84807543
|
[1] |
REAR AXLE
|
ZED
(2-29)
|
| 1. |
84807551
|
[1] |
FRONT AXLE
|
ZED
(2-29)
|
| 1. |
84807552
|
[1] |
REAR AXLE
|
ZED
(2-29)
|
| 1. |
84807544
|
[1] |
FRONT AXLE
|
ZED
(2 to 18, 20 to 22, 30)
|
| 1. |
84807545
|
[1] |
REAR AXLE
|
ZED
(2 to 18, 20 to 22, 30)
|
| 1. |
84807553
|
[1] |
FRONT AXLE
|
ZED
(2 to 18, 20 to 22, 30)
|
| 1. |
84807554
|
[1] |
REAR AXLE
|
ZED
(2 to 18, 20 to 22, 30)
|
| 2. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Shaft
|
| 3. |
84807624
|
[4] |
SEAL
|
ZED
Superseded by part number: 84521823
|
| 4. |
84100482
|
[4] |
RING
|
ZED
|
| 5. |
84100483
|
[4] |
BALL BEARING,75mm ID x 130mm OD x 33.25mm W
|
ZED
Superseded by part number: 26800210
|
| 6. |
84100484
|
[4] |
RING
|
ZED
|
| 7. |
84100485
|
[4] |
BALL BEARING,60mm ID x 110mm OD x 29.75mm W
|
ZED
Superseded by part number: 87622924
|
| 8. |
84100486
|
[4] |
NUT
|
ZED
|
| 9. |
84041875
|
[4] |
PIN
|
ZED
|
| 10. |
84100487
|
[4] |
KIT
|
ZED
|
| 11. |
84014229
|
[32] |
BOLT
|
ZED
Superseded by part number: 87472615
|
| 12. |
84045545
|
[32] |
WHEEL NUT
|
ZED
Superseded by part number: 84288019
|
| 13. |
84014235
|
[8] |
SLEEVE
|
ZED
|
| 14. |
84100574
|
[4] |
SHAFT
|
ZED
|
| 15. |
80300632
|
[4] |
RETAINER
|
ZED
Superseded by part number: 11068676
|
| 16. |
84100575
|
[8] |
SPRING
|
ZED
|
| 17. |
84100576
|
[8] |
BRAKE SHOE
|
ZED
|
| 18. |
84100577
|
[4] |
HUB
|
ZED
|
| 19. |
84014241
|
[8] |
SPRING
|
ZED
|
| 20. |
84429121
|
[4] |
LEVER
|
ZED
|
| 20. |
84807627
|
[1] |
LEVER
|
ZED
RH
|
| 20. |
84807628
|
[1] |
LEVER
|
ZED
LH
|
| 21. |
84814994
|
[4] |
WASHER,26mm ID x 50mm OD x 3mm Thk
|
ZED
|
| 22. |
80370002
|
[4] |
CIRCLIP
|
ZED
Superseded by part number: 370002
|
| 23. |
84014244
|
[8] |
PIN
|
ZED
|
| 24. |
84100491
|
[8] |
SUPPORT
|
ZED
|
| 25. |
86509597
|
[16] |
BOLT,Hex, M30 x 14mm, Cl 8.8
|
NH
|
| 26. |
80140047
|
[16] |
LOCK WASHER
|
ZED
14 MM
|
| 27. |
80100065
|
[16] |
NUT
|
ZED
M14
|
| 28. |
84014242
|
[4] |
CYLINDER
|
ZED
D= 25 MM
|
| 29. |
84100480
|
[4] |
HUB
|
ZED
Superseded by part number: 87354761
|
| 30. |
84100493
|
[4] |
SUPPORT
|
ZED
|
| 31. |
84807633
|
[4] |
SPACER
|
ZED
|
| 32. |
84807532
|
[2] |
PIN
|
ZED
|
| 33. |
84807533
|
[2] |
NUT
|
ZED
M24 x 1.5
|
| 34. |
80412685
|
[2] |
COTTER PIN
|
ZED
Superseded by part number: 412685
|
