纽荷兰零件查询(E70SR) - MIDI CRAWLER EXCAVATOR ASN YT04-07175 (01-050) - GAUGE ASSY, CLUSTER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
975 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT59S00006F2 | [1] | VACUUM GAUGE | KOBASSY, CLUSTER |
| 2. | YT59S00001S002 | [1] | COVER | KOB |
| 3. | YT59S00001S003 | [1] | COVER | KOB |
| 4. | YT59S00001S004 | [1] | COVER | KOB |
| 5. | YT59S00001S005 | [1] | METER | KOB |
| 6. | YT59S00001S006 | [1] | GAUGE | KOB |
| 7. | YT59S00001S007 | [1] | BOARD | KOBPRINTED |
| 8. | YT59S00001S008 | [1] | LENS | KOB |
| 9. | YT59S00001S009 | [1] | BRACKET | KOB |
| 10. | LC59S00001S013 | [3] | BULB | KOBSOCKET ASSY |
| 11. | LC59S00001S012 | [1] | GASKET | KOB |
| 12. | YT59S00001S012 | [8] | BULB | KOBSOCKET ASSY Superseded by part number: LC59S00001S013 |
| 13. | LC59S00001S014 | [1] | SOCKET ASSY | KOBSOCKET, ASSY |
| 14. | YT59S00001S014 | [1] | SOCKET ASSY | KOBSOCKET, ASSY |
| 15. | YT59S00001S015 | [4] | NUT | KOB |
| 16. | YT59S00001S016 | [4] | SCREW,Phillips Drive, Pan HD, M4 x 10mm | KOBTAPPING Superseded by part number: ZS31C04010 |
| 17. | LC59S00001S015 | [4] | SCREW | KOB |
| 18. | LC59S00001S016 | [6] | SCREW | KOBTAPPING |
| 19. | LC59S00001S017 | [6] | SCREW | KOB |
| 20. | YT59S00007S001 | [1] | COVER | KOBCOVER Superseded by part number: YT59S00001S001 |
