纽荷兰零件查询(E70SR) - MIDI CRAWLER EXCAVATOR ASN YT04-07175 (01-051[02]) - CONTROLLER GROUP (5 LIGHT) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
693 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT22E00032F5 | [1] | CONTROLLER GROUP, ASSY | |
| A1. | YY22E01019P1 | [1] | BOX | KOB |
| A6. | YT22E01019P1 | [2] | BRACKET | KOB |
| A7. | YT50E00001F1 | [1] | SWITCH | KOBASSY (SWING PARKING RELEASE) Superseded by part number: YN50S00047P1 |
| A8. | EN24S00008P1 | [7] | RELAY | KOB |
| A10. | 2427Z1594D006 | [1] | TRIM PANEL | KOB |
| A11. | 2427Z1594D008 | [2] | PROTECTION STRIP | KOBTRIM Superseded by part number: S16539-17000 |
| A12. | 2427Z1594D028 | [2] | TRIM PANEL | KOB |
| A13. | YT22E01006P1 | [1] | LABEL | KOB |
| A14. | ZM61C06012 | [13] | BOLT | KOBSEMS |
| A15. | ZM61C06016 | [5] | BOLT | KOBSEMS |
| A16. | 2427Z1594D003 | [1] | SOFT TRIM | KOB |
| A18. | YT14E00023F1 | [1] | WIRE HARNESS | KOBHARNESS ASSY, CAB |
| A18-3. | ZM61C06020 | [2] | BOLT | KOBSEMS |
| A18-4. | 2432R233D1 | [2] | CLIP | KOB |
| A18-5. | YN03E01001D5 | [6] | CLIP | KOB |
| A18-6. | YT14E01069P1 | [1] | HARNESS | KOB |
| A18-6B. | YT73E00003F2 | [1] | FUSE | KOBASSY |
| A18-6Ba. | YN73E00001S001 | [1] | BASE | KOB |
| A18-6Bb. | YN73E00001S002 | [1] | COVER | KOB |
| A18-6Be. | 2479R655S8 | [11] | FUSE,10 Amp | KOB(10A) Superseded by part number: 87522597 |
| A18-6Bf. | 2479R655S9 | [7] | FUSE | KOB(20A) |
| A18-6Bh. | 2479R655S11 | [1] | FUSE,30 Amp | KOB(30A) Superseded by part number: YN73E00001S022 |
| A18-6BJ. | YT73E01008P1 | [1] | LABEL | |
| A22. | YN25S00001P1 | [1] | TIMER | KOB |
| A23. | ZW16P06000 | [7] | WASHER | KOB |
| A37. | YT22E00031F1 | [1] | ECU | KOBASSY (MECHA-TRO) |
| A38. | LC24S00001P1 | [3] | RELAY | KOB |
| A39. | YT22E01039P1 | [1] | U-BRACKET | KOB |
| A40. | YT25S00003F1 | [1] | COUNTER | KOBCOUNTER ASSY |
| A43. | YT22E01040P1 | [1] | LABEL | |
| A44. | YT24S00002P1 | [1] | RELAY | KOB |
| . . | YT22E00020F2 | [1] | CONTROLLER INSTAL | |
| B1. | ZM22C10025 | [3] | BOLT | KOBSEMS |
| B2. | YT22E01026P1 | [1] | INDICATOR | KOB |
| B3. | 2432R233D3 | [1] | CLIP | KOB |
| B4. | ZM22C10030 | [1] | BOLT | KOBM10x1.50x30mm (Incls. Washer & Lockwasher) |
| B5. | 2447Z156D1 | [1] | BUZZER | KOB |
| B6. | ZM41C04012 | [2] | BOLT | KOBSEMS |
| B7. | YT25S00001P1 | [1] | RELAY | KOBTIMER |
| B9. | YT22E01034P2 | [1] | U-BRACKET | KOB |
| B10. | PE21C01070DL | [1] | INSULATING PANEL | KOBTRIM |
| B11. | PE21C01070DK | [1] | INSULATING PANEL | KOBTRIM |
| B12. | PE21C01070D8 | [1] | INSULATING PANEL | KOBTRIM |
| B13. | PA22C01024D4 | [1] | PANEL | KOBTRIM |
