纽荷兰零件查询(E70SR) - MIDI CRAWLER EXCAVATOR ASN YT04-07175 (01-055) - CONDITIONER ASSY, AIR, P/N YT20M00008F3 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
752 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT20M00008F3 | [1] | CONDITIONER ASSY, AIR | |
| 1. | YT20M00009F1 | [1] | AIR CONDITIONER | KOBASSY, SEE FIG. 01-056 |
| 3. | YT91V00001F1 | [1] | AIR COMPRESSOR | KOBASSY, AIR, SEE FIG. 01-058 |
| 4. | YT20M01104F1 | [1] | PANEL | KOBASSY, SEE FIG. 01-059 |
| 5. | YT95V00001F1 | [1] | FILTER ASSY | KOBAIR, SEE FIG. 01-059 |
| 8. | YT96V00001F3 | [1] | HEATER | KOBDRIER ASSY, AIR, SEE FIG. 01-057 |
| 9. | YT20M01060P1 | [1] | CONDENSER | KOB Superseded by part number: YT20M01060P2 |
