| 1. |
84078017
|
[1] |
SUPPORTING ARM
|
ZED
LH
|
| 1. |
84078011
|
[1] |
SUPPORTING ARM
|
ZED
RH
|
| 2. |
80921928
|
[4] |
RING
|
ZED
Superseded by part number: 921928
|
| 3. |
80378248
|
[2] |
WASHER
|
ZED
25 MM Superseded by part number: 378248
|
| 4. |
80435967
|
[2] |
SPRING
|
ZED
Superseded by part number: 435967
|
| 5. |
89503523
|
[2] |
PIN
|
ZED
Superseded by part number: 412660
|
| 6. |
84022829
|
[2] |
PIN
|
ZED
Superseded by part number: 412689
|
| 7. |
89814947
|
[2] |
SUPPORT
|
ZED
Superseded by part number: 9814947
|
| 8. |
89839002
|
[6] |
EXTERNAL REFLECTOR
|
ZED
Superseded by part number: 9839002
|
| 9. |
84073095
|
[2] |
WIRE HARNESS
|
ZED
|
| 10. |
80449531
|
[2] |
LAMP
|
ZED
Superseded by part number: 449531
|
| 11. |
80353078
|
[2] |
BULB
|
ZED
Superseded by part number: 3050199R91
|
| 12. |
80336483
|
[2] |
LAMP, TAIL
|
ZED
LIGHT, TAIL White Superseded by part number: 336483
|
| 13. |
80470016
|
[2] |
BULB
|
ZED
Superseded by part number: E35556
|
| 14. |
84072224
|
[1] |
WIRE HARNESS
|
ZED
|
| 14. |
84075286
|
[1] |
WIRE HARNESS
|
ZED
, Serial Range: -C439
|
| 14. |
84459691
|
[1] |
WIRE HARNESS
|
ZED
, Start Serial: D440
|
| 15. |
80398224
|
[1] |
POWER SOCKET
|
ZED
Superseded by part number: 83959716
|
| 17. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Rivet
|
| 18. |
80746294
|
[4] |
LAMP REFLECTOR
|
ZED
|
| 19. |
80322356
|
[1] |
WASHER
|
ZED
Superseded by part number: 322356
|
| 20. |
80411809
|
[1] |
GROMMET
|
ZED
Superseded by part number: 411809
|
| 21. |
84037090
|
[2] |
TAIL LAMP,12V, 21W, Amber/Red
|
ZED
, Serial Range: (22-25)
|
| 23. |
80398877
|
[2] |
BULB
|
ZED
12 V - 21 W Superseded by part number: 14148190
|
| 24. |
80418870
|
[2] |
BULB
|
ZED
12 V - 5 W Superseded by part number: 14149590
|
| 26. |
84076074
|
[1] |
WIRE HARNESS
|
ZED
|
| 27. |
84100424
|
[1] |
SUPPORT
|
ZED
|
| 27. |
84320762
|
[1] |
PLATE
|
ZED
|
| 28. |
80445502
|
[1] |
LAMP
|
ZED
Superseded by part number: 445502
|
| 29. |
80470017
|
[1] |
BULB
|
ZED
12 V - 5 W Superseded by part number: 10863090
|
| 30. |
80385682
|
[2] |
BOLT
|
ZED
M4 x 30 Superseded by part number: 385682
|
| 31. |
80322355
|
[2] |
WASHER
|
ZED
4 MM Superseded by part number: 322355
|
| 32. |
80100012
|
[2] |
NUT
|
ZED
M4 Superseded by part number: 57121
|
| 33. |
NS
|
[1] |
NOT SERVICED
|
BAS
Cable, Harness
|
| 34. |
80799266
|
[1] |
LAMP REFLECTOR
|
ZED
White Superseded by part number: 799266
|
| 35. |
86547710
|
[1] |
EMBLEM
|
ZED
KIT SMV
|
| 36. |
84100426
|
[1] |
PLATE
|
ZED
|
| 37. |
80120100
|
[1] |
BOLT,M6 x 1 x 20mm
|
ZED
Superseded by part number: 120100
|
| 37. |
120037
|
[6] |
CARRIAGE BOLT,Short Nk, M8 x 20mm, Cl 8.8, Full Thd
|
ZED
, Serial Range: -C619 Superseded by part number: 86507486
|
| 37. |
86507486
|
[4] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
, Start Serial: D620
|
| 38. |
80412649
|
[1] |
LOCK WASHER
|
ZED
6 MM Superseded by part number: 412649
|
| 39. |
15896221
|
[1] |
NUT,Hex, M6, 5.20mm High, Cl 10
|
ZED
Superseded by part number: 86500688
|
| 39. |
9706690
|
[1] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 40. |
84818443
|
[1] |
CLAMP,16.3mm ID, 6.7mm Bolt Hole, P Type
|
ZED
|
| 42. |
89993154
|
[1] |
CLAMP
|
ZED
Superseded by part number: 263117
|
| 43. |
80452802
|
[4] |
GROMMET
|
ZED
Superseded by part number: 452802
|
| 45. |
86561136
|
[1] |
MODULE
|
NH
|
| 46. |
89706703
|
[2] |
BOLT
|
ZED
M6 x 20 Superseded by part number: 9706703
|
| 47. |
80412618
|
[2] |
WASHER
|
ZED
Superseded by part number: 412618
|
| 48. |
84818442
|
[1] |
CLAMP,13.3mm ID, 6.7mm Bolt Hole, P Type
|
ZED
|
| 49. |
89512290
|
[10] |
RIVET
|
ZED
Superseded by part number: 9512290
|
| 50. |
84007699
|
[1] |
COVER PLATE
|
ZED
|
| 51. |
84058832
|
[3] |
CLIP
|
ZED
|
| 52. |
80445394
|
[3] |
RIVET
|
ZED
Superseded by part number: 151-573
|
| 53. |
80675162
|
[1] |
WIRE CLAMP
|
ZED
Superseded by part number: 675162
|
| 54. |
86508568
|
[4] |
BOLT,Hex, M6 x 1 x 16mm, Cl 8.8
|
NH
|
| 55. |
80322357
|
[1] |
LOCK WASHER,Belleville, M6
|
ZED
6 MM Superseded by part number: 322357
|
| 55. |
322358
|
[1] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 56. |
120104
|
[8] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 57. |
80322358
|
[16] |
LOCK WASHER
|
ZED
8 MM Superseded by part number: 322358
|
| 58. |
89706690
|
[8] |
NUT,M8, Cl 8
|
ZED
Superseded by part number: 43362
|
| 59. |
80301572
|
[3] |
SCREW
|
ZED
M4 x 35 Superseded by part number: 86585707
|
| 60. |
86511830
|
[4] |
SCREW,Phillips Drive, Pan HD, M6 x 20mm, Cl 4.8
|
ZED
M6 x 20
|
| 61. |
80325911
|
[8] |
RIVET
|
ZED
Superseded by part number: 325911
|
| 62. |
84607381
|
[4] |
PLATE
|
ZED
|
| 63. |
84429146
|
[2] |
SUPPORT
|
ZED
|
| 64. |
84429154
|
[1] |
SUPPORT
|
ZED
RH, Serial Range: -C535
|
| 64. |
87316648
|
[1] |
SUPPORT
|
ZED
RH, Serial Range: -F536619
|
| 64. |
87648374
|
[1] |
SUPPORT
|
ZED
RH, Start Serial: D620
|
| 64. |
84429152
|
[1] |
SUPPORT
|
ZED
LH, Serial Range: -C535
|
| 64. |
87316644
|
[1] |
SUPPORT
|
ZED
LH, Serial Range: -F536619
|
| 64. |
87648372
|
[1] |
SUPPORT
|
ZED
LH, Start Serial: D620
|
| 65. |
84459692
|
[1] |
WIRE HARNESS
|
ZED
, Start Serial: D440
|
