凯斯零件查询(LBX332R) - BIG RECTANGULAR BALER ''ROTOR CUTTER'' (3/03-12/08) (06.04[01]) - SIDE LIGHTS, DENMARK Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
413 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84073089
|
[2] |
WIRE HARNESS
|
ZED
, Serial Range: -C439
|
| 1. |
84459690
|
[2] |
WIRE HARNESS
|
ZED
, Start Serial: D440
|
| 2. |
84058158
|
[6] |
SIDE LAMP ASSY
|
ZED
|
| 3. |
80100012
|
[12] |
NUT
|
ZED
M4 Superseded by part number: 57121
|
| 4. |
80322355
|
[12] |
WASHER
|
ZED
4 MM Superseded by part number: 322355
|
| 5. |
86511042
|
[12] |
SCREW,Pan Head, M4 x 0.7 x 16mm, Cl 4.8
|
ZED
Superseded by part number: 13272214
|
| 6. |
84058228
|
[6] |
BULB,12V, 5W
|
ZED
12 V - 4 W
|
| 7. |
80323788
|
[3] |
GROMMET
|
ZED
Superseded by part number: 323788
|
| 8. |
80399986
|
[2] |
GROMMET
|
ZED
Superseded by part number: 399986
|
| 9. |
89507807
|
[8] |
CLAMP
|
ZED
Superseded by part number: 9507807
|
| 10. |
89512290
|
[8] |
RIVET
|
ZED
Superseded by part number: 9512290
|
| 11. |
80323597
|
[4] |
STRAP
|
ZED
Superseded by part number: 14560287
|
| 12. |
80322356
|
[4] |
WASHER
|
ZED
5.1 MM Superseded by part number: 322356
|
| 13. |
80675162
|
[13] |
WIRE CLAMP
|
ZED
Superseded by part number: 675162
|
| 14. |
43138
|
[9] |
BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8
|
NH
|
| 15. |
80378244
|
[9] |
LOCK WASHER
|
ZED
10 MM Superseded by part number: 378244
|
| 16. |
80140045
|
[9] |
WASHER
|
ZED
10 MM Superseded by part number: 140045
|
| 17. |
100016
|
[9] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 18. |
84459692
|
[1] |
WIRE HARNESS
|
ZED
, Start Serial: D440
|
