纽荷兰零件查询(E70SR) - MIDI CRAWLER EXCAVATOR ASN YT04-07175 (01-066[04]) - HARNESS ASSY, CAB, (P/N YT14E00019F1) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
222 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT14E00019F1 | [1] | HARNESS ASSY, CAB (KCME, FK) | |
| . . | YT14E00019F2 | [1] | HARNESS ASSY, CAB (SOUTHEAST ASIA) | |
| 1. | YT14E01062P1 | [1] | HARNESS | KOB |
| 2. | YT14E01065P1 | [1] | HARNESS | KOB(F1 ONLY) |
| 3. | PY01P01043D4 | [3] | CABLE TIE,4.80mm W x 251mm L | KOB |
| 4. | PY01P01043D7 | [2] | CABLE TIE,4.80mm W x 445mm L | KOB, Serial Range: YT04-07175-YT04-07435 |
| 5. | YN03E01001D5 | [3] | CLIP | KOB |
| 6. | YX14E01004P1 | [1] | GROMMET | KOB |
| 7. | YT14E01061P1 | [1] | HARNESS | KOB |
| 9. | YT14E01036P1 | [1] | WIRE HARNESS | KOB(F2 ONLY) |
