纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-082[00]) - LIGHT INSTALLATION, BOOM New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
353 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LE80E00002F1 | [1] | BOOM | KOBLight Instal |
| 1. | YN80S00012F1 | [1] | LIGHT | KOB Superseded by part number: 2456R442F1 |
| 2. | YN80S00012S012 | [1] | BULB | KOB Superseded by part number: YT80S00002S005 |
| 3. | 2416T13056 | [1] | BRACKET | KOB |
| 4. | ZS18C10020 | [1] | SCREW,Hex, M10 x 20mm | KOBCap |
| 5. | 2418R323D11 | [1] | WASHER | KOB |
| 6. | 2418R323D13 | [1] | LOCK WASHER | KOB |
