纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (03-002[00]) - BOOM, HOE 3.67M New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
617 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LF02B00025F1 | [1] | Hoe 3.67M | |
| 1. | LF02B00026F1 | [1] | BOOM | KOBHoe |
| 2. | LF02B00023F1 | [1] | BOOM | KOBHoe |
| 3. | LF02B00022P1 | [1] | BOOM | KOBHoe |
| 4. | YT02B01212P1 | [2] | BUSHING | KOB |
| 5. | LF02B00012P1 | [1] | BOOM | KOBHoe |
| 6. | YT12B01227P1 | [4] | BLOCK | KOBTapped |
| 7. | YT02B01149P1 | [2] | BLOCK | KOBTapped |
| 8. | LF02B01035P1 | [1] | BLOCK | KOBTapped |
| 9. | HY35B10032G1 | [3] | BLOCK | KOBTapped |
| 10. | 2416T9878 | [1] | BLOCK,M10 Thd Hole - 16mm Thk x 32mm W x 60mm L | KOBTapped |
| 11. | 2416T12922 | [2] | BLOCK | KOBTapped |
| 12. | 2418T23218 | [1] | PLATE | KOB |
| 13. | YT02B01146P1 | [2] | BRACKET | KOB |
| 14. | YT02B01147P1 | [1] | Tapped | |
| 15. | 2416T9804 | [1] | BLOCK | KOBTapped |
| 16. | YT02B01201P1 | [2] | BLOCK | KOBTapped |
| 17. | 2445R138D3 | [2] | SEAL,60mm ID x 75mm OD x 4mm Thk | KOBDust |
