纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (03-004[00]) - BOOM GROUP New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
602 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LF02B00016F1 | [1] | | |
| 1. | 2444R1117D090 | [1] | HOSE,6.40mm ID x 900mm L | KOB Superseded by part number: HX21E04090DY |
| 2. | ZG91V02000 | [1] | LUBE NIPPLE | KOB |
| 3. | ZG91S02000 | [1] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB |
| 4. | YR02B01035P1 | [1] | COVER | KOB |
| 5. | 2420T7541 | [1] | SCREW | KOBCap |
| 6. | 2417T539 | [1] | SPRING | KOB |
| 7. | ZW26X12000 | [1] | WASHER | KOB |
| 8. | 2418T22593 | [1] | WASHER | KOB |
| 9. | PY02B01064P1 | [2] | TUBE | KOB |
| 10. | PY01P01043D3 | [1] | CABLE TIE,188mm L | KOB |
