神钢零件查询(K935) - EXCAVATOR SUPPLEMENT ASN LU00154 (1/76-12/03) (06-008) - ROLLER ASSY P/N 24100J1849F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
752 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J1849F1 | [1] | ROLLER | KOB |
| 1. | 2413N210 | [1] | ROLLER | ROLLER |
| 2. | 2410P427D1 | [1] | SHAFT | SHAFT |
| 3. | B05P0025 | [2] | BUSHING | KOB |
| 4. | 2418P3706 | [1] | COLLAR | COLLAR |
| 6. | 2416T3619 | [1] | PLATE | |
| 8. | ZE82T04000 | [1] | PLUG | KOB1/4" PT |
| 9. | R45P0018D13 | [1] | SEAL | KOB Superseded by part number: ZD57F11032 |
| 10. | ZP26D08022 | [1] | PIN, SPRING | PIN, SPRING |
| 11. | ZD11G13500 | [1] | O-RING,134.40mm ID x 140.60mm OD x 3.10mm | KOB |
| 12. | ZD11G08000 | [1] | O-RING,79.40mm ID x 85.60mm OD x 3.10mm | KOBID 79.40 ± 0.69 x OD 85mm |
| 13. | ZS11C10025 | [4] | CAP,Hex, M10 x 25mm, Cl 4.8 | KOBScrew -- M10x1.50x25mm Superseded by part number: ZS18C10025 |
| 14. | ZS13C12025 | [3] | SCREW | KOBM12x1.75x25mm Superseded by part number: ZS18C12025 |
| 15. | ZW22X10000 | [4] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 16. | ZP26D08016 | [1] | ROLL PIN | KOBSPRING |
| 17. | 2414P1058C2 | [1] | COVER | |
