纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (03-011[01]) - BOOM CYLINDER INSTALLATION New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
564 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LF02B00013F1 | [1] | | |
| 1. | LF02B00014F1 | [1] | CYLINDER | KOBInstal |
| 2. | YT02B01220P1 | [1] | PIN | KOB |
| 3. | LF02B01008P1 | [1] | PIN | KOB |
| 4. | HS18C12125G2 | [1] | SCREW | KOBCap |
| 5. | ZM73C10020 | [1] | BOLT,M10x20mm - Course Thread | KOBSems |
| 6. | 2418T21137 | [1] | WASHER | KOB |
| 7. | ZN18C12010 | [2] | NUT | KOB |
| 8. | YT02B01008D1 | [1] | SHIM | KOB0.5 |
| 9. | B16T0442D93 | [1] | SHIM,120mm OD x 72mm ID x 0.9mm Thk | KOB0.9 |
| 10. | YT02B01008D2 | [1] | SHIM | KOB1.2 |
| 11. | YR02B01262P1 | [2] | SHIM | KOB2.0 |
| 12. | B16T0442D82 | [1] | SHIM,120mm OD x 77mm ID x 0.5mm Thk | KOB0.5 |
| 13. | B16T0442D81 | [1] | SHIM,120mm OD x 77mm ID x 0.9mm Thk | KOB0.9 |
| 14. | B16T0442D80 | [1] | SHIM,120mm OD x 77mm ID x 1.2mm Thk | KOB1.2 |
| 15. | YR02B01261P1 | [2] | SHIM,2mm Thk | KOB2.0 |
| 16. | YT01V00030F1 | [1] | LIFT CYLINDER | KOBBoom |
