凯斯零件查询(LBX332R) - BIG RECTANGULAR BALER ''ROTOR CUTTER'' (3/03-12/08) (06.69[01]) - CABLE HARNESS : 84072224 - FOR NA ONLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
989 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
441166
|
[1] |
TERMINAL CONNECTOR,Tin, 0.7 - 2.0mm
|
ZED
|
| 2. |
441159
|
[1] |
CONTACT HOUSING,Female, 1 Pole
|
ZED
Superseded by part number: 87675193
|
| 3. |
430026
|
[1] |
TERMINAL CONNECTOR,1 - 2.5mm
|
ZED
|
| 4. |
335482
|
[1] |
TERMINAL CONNECTOR,1.5 - 2.5 mm2
|
ZED
Superseded by part number: 80335482
|
| X120. |
86500036
|
[1] |
TERMINAL,Female, Nickel, 0.75 - 2mm
|
PA
X120
|
| . . |
84074643
|
[1] |
CONTACT HOUSING,Female, 6 Pole
|
ZED
|
| . . |
84074641
|
[1] |
WEDGE
|
ZED
Superseded by part number: 87694150
|
| X143. |
84074631
|
[1] |
CONTACT HOUSING,Female, 2 Pole
|
ZED
X143 Superseded by part number: 87695582
|
| . . |
84074638
|
[1] |
LOCKING TAB,Locking Wedge, Green
|
ZED
|
| . . |
84068583
|
[1] |
PLUG,12 - 16 Ga, White
|
ZED
Superseded by part number: 87695652
|
| . . |
84074630
|
[1] |
CONTACT HOUSING,Male, 2 Pole
|
ZED
X143
|
| . . |
86500166
|
[1] |
ELEC CONNECTOR
|
ZED
Superseded by part number: 225318C1
|
| X208. |
426199
|
[1] |
TERMINAL CONNECTOR,Female, 1 - 2.5 mm2
|
ZED
X208
|
| . . |
853543
|
[1] |
ELEC CONNECTOR,Female
|
ZED
|
