凯斯零件查询(LBX332R) - BIG RECTANGULAR BALER ''ROTOR CUTTER'' (3/03-12/08) (06.79[01]) - CABLE HARNESS : 84449607 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
1005 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
441166
|
[1] |
TERMINAL CONNECTOR,Tin, 0.7 - 2.0mm
|
ZED
|
| 2. |
441159
|
[1] |
CONTACT HOUSING,Female, 1 Pole
|
ZED
Superseded by part number: 87675193
|
| S006. |
84819783
|
[1] |
TERMINAL CONNECTOR
|
ZED
S6
|
| . . |
84819781
|
[1] |
ELEC CONNECTOR,Female
|
ZED
|
| . . |
84819785
|
[1] |
PLUG
|
ZED
|
| . . |
84819782
|
[1] |
PLUG
|
ZED
Superseded by part number: 82863648
|
| X141. |
86500036
|
[1] |
TERMINAL,Female, Nickel, 0.75 - 2mm
|
PA
X141
|
| . . |
84074631
|
[1] |
CONTACT HOUSING,Female, 2 Pole
|
ZED
Superseded by part number: 87695582
|
| . . |
84074638
|
[1] |
LOCKING TAB,Locking Wedge, Green
|
ZED
|
| . . |
84074637
|
[1] |
WIRE CONNECTOR,Female
|
ZED
|
| . . |
84074640
|
[1] |
LOCKING TAB,Wedge Lock
|
ZED
Superseded by part number: 86622299
|
| . . |
446133
|
[1] |
ELEC CONNECTOR,Female, 2 Pin
|
ZED
|
