凯斯零件查询(LBX332R) - BIG RECTANGULAR BALER ''ROTOR CUTTER'' (3/03-12/08) (06.82[01]) - CABLE HARNESS : 84459691 - NOT FOR NA - D440 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
181 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
441166
|
[1] |
TERMINAL CONNECTOR,Tin, 0.7 - 2.0mm
|
ZED
|
| 2. |
441159
|
[1] |
CONTACT HOUSING,Female, 1 Pole
|
ZED
Superseded by part number: 87675193
|
| 3. |
430026
|
[1] |
TERMINAL CONNECTOR,1 - 2.5mm
|
ZED
|
| 4. |
335482
|
[1] |
TERMINAL CONNECTOR,1.5 - 2.5 mm2
|
ZED
Superseded by part number: 80335482
|
| X123. |
426199
|
[1] |
TERMINAL CONNECTOR,Female, 1 - 2.5 mm2
|
ZED
X123
|
| . . |
398225
|
[1] |
MULTIPOLE CONNECTOR,7 Pin
|
ZED
|
| X207. |
86500035
|
[1] |
ELEC. TERMINAL PIN,Male, 0.75 - 2mm
|
GI
X207 Superseded by part number: 87695607
|
| . . |
84074636
|
[1] |
WIRE CONNECTOR,Male
|
ZED
Superseded by part number: 89861350
|
| . . |
9861376
|
[1] |
CONTACT HOUSING
|
GI
Superseded by part number: 87694145
|
