凯斯零件查询(LBX332R) - BIG RECTANGULAR BALER ''ROTOR CUTTER'' (3/03-12/08) (06.99[02]) - CONNECTORS - FROM 80445522 TO 84058194 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
795 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
445522
|
[1] |
TERMINAL CONNECTOR,Tin, 1.00 - 2.50mm
|
ZED
|
| 2. |
80445526
|
[1] |
COLLAR
|
ZED
|
| 3. |
80445745
|
[1] |
WIRE CONNECTOR
|
ZED
Superseded by part number: 87675194
|
| 4. |
445746
|
[1] |
ELEC CONNECTOR,Male, 3 Pin
|
ZED
Superseded by part number: 82015694
|
| 5. |
80446236
|
[1] |
CABLE TERMINAL
|
ZED
0.5 - 1.5 MM²
|
| 6. |
447569
|
[1] |
MULTIPOLE CONNECTOR,Male, 16 Pole
|
ZED
Superseded by part number: 87687234
|
| 7. |
80447904
|
[1] |
WIRE CONNECTOR
|
ZED
Superseded by part number: 447904
|
| 8. |
455780
|
[1] |
TERMINAL CONNECTOR,16 - 20 mm2
|
ZED
|
| 9. |
751307
|
[1] |
MULTIPOLE CONNECTOR,Female, 3 Pole
|
ZED
|
| 10. |
751308
|
[1] |
TERMINAL CONNECTOR
|
ZED
|
| 11. |
900363
|
[1] |
TERMINAL
|
NH
0.8 - 1 MM² Superseded by part number: 87697947
|
| 12. |
80916171
|
[1] |
CABLE TERMINAL
|
ZED
16 - 20 MM²
|
| 13. |
916790
|
[1] |
CONTACT HOUSING,4 Pole
|
ZED
4P-M
|
| 14. |
916791
|
[1] |
CONTACT HOUSING,4 Pole
|
ZED
4P-V
|
| 15. |
916797
|
[1] |
GASKET
|
ZED
Superseded by part number: 80916797
|
| 16. |
80919749
|
[1] |
CABLE TERMINAL
|
ZED
2.5 - 6 MM²
|
| 17. |
84000181
|
[1] |
TERMINAL CONNECTOR
|
ZED
|
| 18. |
84000182
|
[1] |
TERMINAL CONNECTOR,Tin, 1.0 - 2.0mm
|
ZED
|
| 19. |
84004134
|
[1] |
TERMINAL CONNECTOR
|
ZED
|
| 20. |
84004255
|
[1] |
SEAL
|
ZED
2.81 - 3.75 MM²
|
| 21. |
84004256
|
[1] |
CLAMP
|
ZED
|
| 22. |
84007631
|
[1] |
MULTIPOLE CONNECTOR,Female, 5 Pole
|
ZED
|
| 23. |
84015523
|
[1] |
WIRE CONNECTOR,Female
|
ZED
|
| 24. |
84019407
|
[1] |
ELEC CONNECTOR
|
ZED
|
| 25. |
84038072
|
[1] |
CAP COVER
|
ZED
|
| 26. |
84058011
|
[1] |
MULTIPOLE CONNECTOR,Female, 40 Pole
|
ZED
Superseded by part number: 225414C1
|
| 27. |
84058188
|
[1] |
CONTACT HOUSING
|
ZED
|
| 28. |
84058194
|
[1] |
PLUG
|
ZED
|
