神钢零件查询(MD140BLC) - EXCAVATOR BTW YP1001 - YP1281 (1/80-12/06) (01-006) - TANK ASSY, HYDR Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
266 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 22. | 2446U215F1 | [1] | FILTER, DRAIN | FILTER, DRAIN |
| 22-1. | 2446U215S01 | [1] | CONTAINER | KOB |
| 22-2. | 2446U175S2 | [1] | VALVE | KOB |
| 22-3. | 2446U175S3 | [1] | SPARE PART | HITCARTRIDGE Superseded by part number: 2446U215S5P |
| 22-4. | 2446U215S04 | [1] | NAME-PLATE | |
| 23. | ZA33F22008 | [1] | 90 ELBOW,M30 x 1.5 ORB x 1/2" NPT | KOB90° -- 1/2" PF - M30x1.50x34mm Long (Incls. O-Ring ZD12P02400) |
| 24. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 25. | ZS18C12030 | [4] | SCREW,Hex, M12 x 30mm | KOBM12x1.75x30mm |
| 26. | 2444Z2322 | [1] | TEE | KOB |
| 27. | ZH32X08000 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 1/2" x PF 1/2", O-Ring | KOBElbow, 90° -- 1/2"PT (Incls. O-Ring ZD12P01800) |
| 28. | ZA93N22000 | [1] | TUBE NUT | KOB |
| 29. | ZA93S22000 | [1] | RING | KOB |
| 30. | 2489R302F1 | [1] | SWITCH | KOB |
| 30-1. | 2489R302S1 | [1] | SWITCH | KOB Superseded by part number: 77260484, 2489R302F1 |
| 30-2. | 2489R302S2 | [1] | O-RING | KOB |
| 31. | ZS23C06010 | [3] | SCREW,Hex Socket Head, M6 x 10mm | KOBM06x1.0x10mm |
| 32. | ZW22K06000 | [3] | LOCK WASHER | KOBID 06 x OD 10 x Th 1.5mm |
| 35. | ZC45X06007 | [1] | CLIP | |
| 36. | ZS18C06016 | [1] | SCREW,Hex, M6 x 16mm | KOBM06x1.0x16mm |
| 37. | ZW26X06000 | [1] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 38. | 2446U215F2 | [1] | HYDRAULIC OIL FILTER | KOB |
| 38-1. | 2446U215S01 | [1] | CONTAINER | KOB |
| 38-2. | 2446U175S2 | [1] | VALVE | KOB |
| 38-4. | 2446U215S04 | [1] | NAME-PLATE | |
| 38-5. | 2446U215S5 | [1] | CARTRIDGE | KOB Superseded by part number: 2446U215S5P |
| 41. | ZE72X16000 | [1] | PLUG | KOB(Incls. O-Ring ZD12P02900) |
| . . | 24046Z15 | [1] | ELEMENT | KOB Superseded by part number: 24046Z15P |
