神钢零件查询(MD140C) - EXCAVATOR BTW YPU0301 - YPU0500 (1/80-12/06) (11-001[01]) - LABEL, NAME-PLATE Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
904 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J13830F2 | [1] | LABEL | KOBLABEL |
| 3. | 2432J2160 | [1] | NAME PLATE | NAME PLATE |
| 4. | 2432J2161 | [2] | LABEL | KOB |
| 5. | 2432P2528 | [1] | LABEL | LABEL |
| 6. | 2432P2529 | [1] | LABEL | KOB |
| 7. | 2432P2530 | [1] | LABEL | KOB |
| 11. | 2432P2531 | [1] | LABEL | KOB |
| 12. | 2432P2532 | [1] | LABEL | |
| 13. | 2432P2533 | [1] | LABEL | |
| 14. | 2432P2534 | [1] | LABEL | |
| 15. | 2432P2535 | [1] | LABEL | |
| 16. | 2432P2536D2 | [1] | LABEL | KOB |
| 17. | 2432P2536D3 | [2] | LABEL | KOB |
| 19. | 2432P2538 | [1] | LABEL, Serial Range: YPU00301-YPU00387 | LABEL, Serial Range: YPU00301-YPU00387 |
| . . | 2432P2665 | [1] | LABEL | KOB, Start Serial: YPU00388 |
| 22. | 2432P2546D1 | [6] | LABEL | KOB |
| 25. | 2427Z329 | [1] | SHEET | KOBAnti-Slip (300x150mm) |
| 26. | 2427Z1432 | [3] | SHEET | KOBAnti-Slip (300x110mm) |
| 27. | 2418T10311 | [2] | PLATE | KOBØ30mm round Superseded by part number: 2418T27058 |
| 28. | 2432T4925 | [2] | LABEL | KOBØ40mm Transparent round |
| 30. | 2432T2283 | [1] | LABEL | KOBDecal, Fuel location |
| 31. | 2432T1231 | [1] | DATA PLAQUE | KOBDecal, Warning - |
| 32. | 2432T4781 | [1] | PLATE | KOB |
| 33. | 4020Z64 | [4] | RIVET | KOBOD 5.0 x 6.0mm Long Superseded by part number: 2420P623D7 |
| 35. | 2432T2342 | [1] | LABEL | LABEL |
| 36. | 2432P2165 | [1] | LABEL PLATE, CAUTION | LABEL PLATE, CAUTION |
| 39. | 2432P2633 | [1] | LABEL | KOBDecal, Filled with antifreeze This machine is filled with … |
| 40. | 2432T1215 | [1] | DATA PLAQUE | KOBDecal, Caution - To prevent accidents and bodily injury … |
| 41. | 2432T4962 | [1] | LABEL | KOBDecal, Lock Release |
| 42. | 2432N1097 | [2] | LABEL | KOBDecal, Danger - Stay out of the swing area. |
| 43. | NSS | [1] | NOT SOLD SEPARAT | CONPLATE, CAUTION (BREATHER PART) |
| 44. | 2432N2494 | [1] | LABEL | |
| 45. | 2432P2434 | [3] | LABEL | KOBDecal, Danger - Death or injury may result from … Superseded by part number: YN20T01006P1 |
| 46. | 2422T590 | [1] | REWORK, FRAME 4 - \u00d85.1 holes added | REWORK, FRAME 4 - Ø5.1 holes added |
| 50. | 2432P2579 | [1] | LABEL | KOB |
| 51. | 2432P2476 | [1] | LABEL | KOBDecal, Precautions - Avoid death or serious injury … |
| 52. | 2432T5141 | [1] | LABEL | LABEL |
| 53. | 2432P2470 | [1] | LABEL | LABEL |
| 54. | 2432T5139 | [1] | LABEL | LABEL |
| 55. | 2432T5175 | [1] | LABEL | LABEL |
| 57. | 2432N2490 | [1] | LABEL (STD ARM) | |
| 58. | 2432N2491 | [1] | LABEL (LONG ARM) | |
| 59. | 2432N2492 | [1] | LABEL (SHORT ARM) | |
| 60. | 2432J1350 | [2] | LABEL | KOB |
| 61. | 2432T3904 | [1] | LABEL | KOB |
| 62. | 2432T3925 | [1] | LABEL | LABEL |
| 63". | 2432T3926 | [1] | LABEL | LABEL |
| 64. | 2432T3927 | [1] | LABEL | LABEL |
| 65. | 2432P2615 | [1] | LABEL | KOB |
| 66. | 2432P2616 | [1] | LABEL | KOB |
| 67. | 2432P2626 | [1] | LABEL | KOB |
| 68. | 2432P2629 | [1] | LABEL | KOB |
| 69. | 2432P2630 | [1] | LABEL | KOB |
| 70. | 2432P2627 | [1] | LABEL, Serial Range: YPU00301-YPU00387 | |
| . . | 2432P2666 | [1] | LABEL, Start Serial: YPU00388 | LABEL, Start Serial: YPU00388 |
| 71. | 2432P5271 | [1] | LABEL | |
