纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (06-001[01]) - NAME PLATE INSTALLATION New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
499 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT22T00140F1 | [1] | | |
| 1. | YN20T01049P1 | [1] | LABEL | KOB |
| 2. | PW20T01007P1 | [1] | LABEL | KOB |
| 3. | PE20T01014P1 | [2] | LABEL | KOB |
| 4. | YN20T01010P1 | [1] | LABEL | KOB Superseded by part number: ZL11N00404 |
| 5. | YN20T01813P1 | [2] | LABEL | KOB |
| 6. | YN20T01818P1 | [4] | LABEL | KOB |
| 7. | YN20T01819P1 | [4] | LABEL | KOB |
| 8. | YN20T01012P1 | [1] | CAUTION DECAL | KOB |
| 9. | PM22T00108P1 | [1] | DECAL | KOB |
