神钢零件查询(MD140C) - EXCAVATOR BTW YPU0301 - YPU0500 (1/80-12/06) (06-001) - WIRING ASSY, ELEC Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
125 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J13491F2 | [1] | WIRING ASSY, ELEC, Serial Range: YPU00301-YPU00339 | |
| . . | 24100J13491F4 | [1] | WIRING ASSY, ELEC, Start Serial: YPU00340 | |
| 2. | 2479R1470F1 | [1] | RELAY,24V, 100 Amp | KOB |
| 3. | NSS | [1] | NOT SOLD SEPARAT | CONLIGHT, WORKING |
| 4. | NSS | [2] | NOT SOLD SEPARAT | CONLIGHT, WORKING |
| 5. | 2479U1009F1 | [1] | HORN,24V, 390HZ | KOBHigh (415Hz) Superseded by part number: CM53S00002F1 |
| 6. | 2479U1009F2 | [1] | HORN,24V, 350HZ | KOBLow (390Hz) Superseded by part number: CM53S00002F2 |
| 7. | 2486R87D3 | [1] | NEG BATTERY CABLE | KOB |
| 8. | 2486R88D2 | [1] | ELECTRIC CABLE | KOB |
| 9. | 2486R89D2 | [1] | ELECTRIC CABLE | KOB |
| 10. | 2486R90D3 | [1] | ELECTRIC CABLE | KOB |
| 11. | 2479U1449 | [1] | WIRE HARNESS | KOB |
| 12. | 2479U1396 | [1] | HARNESS | KOB, Serial Range: YPU00301-YPU00339 |
| 13. | 2479U1460 | [1] | HARNESS, WIRING | HARNESS, WIRING |
| 14. | 2479Z1918D1 | [1] | WIRE HARNESS | KOB |
| 15. | 2479R1449 | [1] | WIRE HARNESS | KOB |
| 16. | 2479Z1888 | [1] | HARNESS | KOB Superseded by part number: 2479Z1888D2 |
| 17. | 2479Z2427 | [1] | HARNESS | KOB |
| 19. | ZS18C06010 | [2] | SCREW,Hex, M6 x 10mm | KOBM06x1.0x10mm |
| 20. | ZW26X06000 | [2] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 22. | ZS18C10014 | [2] | SCREW,Hex, M10 x 14mm | KOBM10x1.50x14mm |
| 23. | ZS18C08025 | [4] | SCREW,Hex, M8 x 25mm | KOBM08x1.25x25mm |
| 24. | ZN18C08007 | [2] | NUT | KOBM08x1.25mm |
| 25. | ZW26X08000 | [6] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 26. | ZW16K08000 | [4] | WASHER,8mm ID x 15.5mm OD x 1.6mm Thk | KOBID 08 x OD 15.5 x Th 1.6mm |
| 27. | ZS18F10020 | [1] | BOLT,Hex, M10 x 20mm | KOBM10x1.25x20mm |
| 28. | ZN18C10008 | [1] | NUT | KOBM10x1.50mm |
| 29. | ZW26X10000 | [4] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 30. | ZW16K10000 | [4] | WASHER | KOBID 10.5 x OD 18 x Th 2.0mm |
| 31. | 2432Z290 | [10] | CLIP | KOBWire Ties -- 185mm Long Superseded by part number: PY01P01043D3 |
| 32. | 2432Z290D3 | [5] | CLIP | KOBWire Ties -- 154mm Long Superseded by part number: PY01P01043D3 |
| 41. | 2420Z1188 | [1] | GROMMET | KOB |
| 42. | 2420Z699 | [4] | GROMMET | KOB |
| 43. | 2432R233D3 | [1] | CLIP | KOB50x16x60mm |
| 44. | 2479Z2215 | [1] | INSULATOR | |
| 45. | 24101J316 | [1] | DIAGRAM, WIRING, Serial Range: YPU00301-YPU00339 | |
| 47. | 24101J333 | [1] | DIAGRAM, WIRING, Start Serial: YPU00340 | |
| 48. | 2479U1508 | [1] | HARNESS | KOB(HARNESS, INST-PANEL), Start Serial: YPU00340 |
| 60. | 2479R1473F1 | [1] | HARNESS | KOB |
| 62. | 2479U1478 | [1] | HARNESS, WIRING | |
| 63. | 2479R1909 | [1] | HARNESS | KOB(HARNESS, CAB) |
| 80. | 2479U1297 | [1] | HARNESS | KOB |
| 81. | 2479U1298 | [1] | HARNESS | KOB |
| 82. | 24100J6512S45 | [1] | HARNESS | KOB |
