凯斯零件查询(LBX421R) - BIG RECTANGULAR BALER 'ROTOR CUTTER' (6/01-12/03) (15.02A[01]) - KNOTTER TRANSMISSION Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
482 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84429330
|
[1] |
PTO SHAFT
|
ZED
, Serial Range: (2-7)
|
| 2. |
84806523
|
[1] |
YOKE
|
ZED
|
| 3. |
80418936
|
[1] |
SPIDER
|
ZED
(4), Serial Range: -C263 Superseded by part number: 84355315
|
| 3. |
84429267
|
[1] |
SPIDER
|
ZED
, Start Serial: D264 Superseded by part number: 84355315
|
| 4. |
150024
|
[1] |
LUBE NIPPLE,45 Degree, M8 x 1
|
NH
|
| 5. |
84429266
|
[1] |
YOKE
|
ZED
(6, 7)
|
| 6. |
80100038
|
[1] |
NUT
|
ZED
M12 Superseded by part number: 100038
|
| 7. |
80350460
|
[1] |
SCREW,M12 x 75mm
|
ZED
M12x75 Superseded by part number: 83926667
|
| 8. |
86574241
|
[2] |
FLANGE
|
ZED
Superseded by part number: 86620026
|
| 9. |
80322360
|
[1] |
BEARING ASSY
|
ZED
Superseded by part number: 322360
|
| 10. |
811-10030
|
[3] |
CARRIAGE BOLT,Sht Sq Nk, M10 x 1.5 x 30mm, Cl 8.8
|
CAS
Superseded by part number: 86512446
|
| 11. |
80140045
|
[3] |
WASHER
|
ZED
10MM Superseded by part number: 140045
|
| 12. |
100016
|
[3] |
NUT,M10 x 1.5, Cl 8
|
NH
|
