现代零件查询R500LC-7A BUCKET(1.38M3 SAE HEAPED, L/REACH)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
166 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
61NB-30201BG
|
[1] |
BUCKET ASSY
|
|
| 1. |
61NB-32011BG
|
[1] |
BUCKET WA
|
|
| 1-1. |
61NB-31320
|
[4] |
TOOTH ADAPTER
|
|
| 2. |
61NB-31310BG
|
[4] |
TOOTH POINT
|
|
| 3. |
61E7-0102BG
|
[1] |
SIDE CUTTER(LH)
|
|
| 4. |
61E7-0103BG
|
[1] |
SIDE CUTTER(RH)
|
|
| 5. |
61E7-04620
|
[4] |
TOOTH PIN
|
|
| 6. |
61NB-31110
|
[1] |
BUSHING
|
|
| 7. |
61NB-31120
|
[1] |
PLATE-COVER
|
|
| 8. |
S017-27060D
|
[4] |
BOLT-HEX
|
|
| 9. |
S017-30080D
|
[6] |
BOLT-HEX
|
|
| 10. |
S017-300752
|
[4] |
BOLT-HEX
|
|
| 11. |
S205-30100B
|
[10] |
NUT-HEX
|
|
| 12. |
S411-300006
|
[10] |
WASHER-SPRING
|
|
| 13. |
61E7-04630
|
[4] |
LOCK WASHER
|
|
| 14. |
S441-270004
|
[4] |
WASHER-HARDENED
|
|
| 15. |
64E7-02410
|
[12] |
SHIM(1.0T)
|
|
