神钢零件查询(MD140C) - EXCAVATOR BTW YPU0301 - YPU0500 (1/80-12/06) (09-007) - FLASHER ASSY, SWING Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
357 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100R239F1 | [1] | FLASHER ASSY, SWING | |
| 1. | 2480U306 | [1] | FLASHER UNIT | KOB |
| 2. | 2456R350F1 | [2] | LAMP | LAMP |
| 2-1. | 2456R350S1 | [1] | BODY ASSY | |
| 2-2. | 2456U85S4 | [1] | BULB | KOB24V -- 25W |
| 2-3. | 2456R350S3 | [2] | LENS | LENS |
| 2-4. | 2456R350S4 | [6] | SCREW, TAPPING | |
| 2-5. | 2456R350S5 | [1] | NUT | |
| 2-6. | 2456R350S6 | [1] | WASHER | |
| 3. | 2479Z2442 | [2] | HARNESS | |
| 4. | 2432Z863 | [6] | CLIP | |
| 5. | 2420R1087D1 | [2] | SCREW | KOB Superseded by part number: ZM46C06012 |
